291627-YTG-B-0807
Unitary Products Group 15
TABLE 10: BOTTOM SUPPLY AIR BLOWER PERFORMANCE - 208 VOLT
1
MODEL #
DNH
(Cooling/
Heating)
MTR
SPD
EXTERNAL STATIC PRESSURE - IWG
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00 1.10
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
030
HI - - - - 1115 454 1049 436 967 417 886 398 805 380 676 351 - - - - - -
MED 895 300 853 289 811 278 769 267 697 252 - - - - - - - - - - - -
LOW----------------------
036
HI - - - - - - - - 1458 688 1377 663 1295 639 1147 600 999 561 - - - -
MED 1482 628 1428 613 1374 599 1320 584 1242 556 1163 528 1085 500 961 474 - - - - - -
LOW 1239 510 1184 496 1130 481 1075 467 998 448 922 428 - - - - - - - - - -
042
HI - - 1687 763 1614 737 1540 712 1458 688 1377 663 1295 639 1147 600 - - - - - -
MED 1482 628 1428 613 1374 599 1320 584 1242 556 1163 -528 1085 500 - - - - - - - -
LOW 1239 510 1184 496 1130 481 1075 467 - - - - - - - - - - - - - -
048
HI 1655 771 1609 749 1563 727 1504 698 1444 670 1381 648 1319 626 - - - - - - - -
MED 1499 687 1474 670 1449 653 1400 630 1351 606 1297 583 1242 559 - - - - - - - -
LOW 1418 610 1388 593 1357 576 1327 561 1298 546 1241 523 - - - - - - - - - -
060
(3 tube)
HEAT 1500 245 1500 297 1500 348 1500 400 1500 470 1500 540 1500 610 1500 680 1500 750 1500 820 1500 890
060
(4 & 5 tube)
HEAT 1700 390 1700 443 1700 497 1700 550 1700 620 1700 690 1700 760 1700 830 1700 900 - - - -
060
(factory
settings)
COOL 1800 460 1800 515 1800 570 1800 625 1800 690 1800 755 1800 820 1800 962 - - - - - -
060
(field settings)
COOL 2000 640 2000 700 2000 760 2000 820 2000 928 - - - - - - - - - - - -
1. Above data includes allowances for a dry evaporator coil, gas heat exchanger and no filters. For additional pressure drops, refer to
Tables 12 and 13.
