291627-YTG-B-0807
12 Unitary Products Group
TABLE 7: DNH060 COOLING CAPACITIES - 5 TON
TEMPERATURE
OF AIR ON
CONDENSER COIL
AIR ON EVAPORATOR COIL
1,700 CFM 1,800 CFM 1,900 CFM 2,000 CFM 2,100 CFM
WB °F WB °F WB °F WB °F WB °F
72 67 62 57 72 67 62 57 72 67 62 57 72 67 62 57 72 67 62 57
85 °F
NET CAP.
MBH
66.8 63.1 58.2 57.0 68.2 64.4 59.4 58.2 69.5 65.6 60.6 59.3 69.3 65.4 60.3 59.1 69.0 65.1 60.1 58.9
TOTAL POWER
INPUT kW
5.06 4.96 5.02 4.83 5.13 5.03 5.10 4.90 5.21 5.11 5.17 4.97 5.33 5.24 5.30 5.09 5.46 5.36 5.43 5.22
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 42.8 53.5 58.2 57.0 44.6 55.8 59.4 58.2 46.5 58.1 60.6 59.3 47.8 59.5 60.3 59.1 49.1 61.0 60.1 58.9
83 37.9 48.7 57.7
57.0 39.4 50.6 59.1 58.2 41.0 52.5 60.6 59.3 41.9 53.6 60.3 59.1 42.9 54.8 60.1 58.9
80 33.1 43.8 52.8 54.2 34.3 45.4 54.7 56.1 35.4 47.0 56.6 58.1 36.0 47.7 57.5 58.5 36.6 48.5 58.5
58.9
77 28.2 39.0 48.0 49.4 29.1 40.2 49.5 50.9 29.9 41.4 51.1 52.5 30.1 41.8 51.6 52.6 30.3 42.3 52.2 52.6
74 23.4 34.1 43.1 44.5 23.9 35.0 44.3 45.7 24.4 35.9 45.5 47.0 24.2 35.9 45.7 46.7 24.1 36.0 45.9 46.4
71 - 29.3 38.3 39.7 - 29.8 39.1 40.6 - 30.4 40.0 41.5 - 30.0 39.8 40.8 - 29.7 39.7 40.1
68 - 24.5 33.4 34.8 - 24.6 33.9 35.4 - 24.8 34.4 35.9 - 24.1 33.9 34.9 - 23.5 33.4 33.8
95 °F
NET CAP.
MBH
66.1 61.3 56.8 55.2 67.0 62.1 57.6 56.0 67.9 63.0 58.4 56.7 67.7 62.7 58.2 56.6 67.4 62.5 58.0 56.4
TOTAL POWER
INPUT kW
5.66 5.60 5.58 5.37 5.72 5.66 5.64 5.43 5.78 5.72 5.70 5.49 5.86 5.80 5.77 5.56 5.94 5.87 5.85 5.63
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 42.9 53.4 56.8 55.2 44.6 55.5 57.6 56.0 46.4 57.6 58.4 56.7 47.7 59.1 58.2 56.6 49.0 60.6 58.0 56.4
83 38.1 48.6 55.3
55.2 39.5 50.3 56.9 56.0 40.8 52.0 58.4 56.7 41.8 53.2 58.2 56.6 42.8 54.3 58.0 56.4
80 33.2 43.7 50.5 51.7 34.3 45.1 52.1 53.4 35.3 46.5 53.7 55.0 35.9 47.3 54.6 55.7 36.5 48.1 55.5
56.4
77 28.4 38.9 45.6 46.9 29.1 39.9 46.9 48.2 29.8 40.9 48.1 49.5 30.0 41.4 48.7 49.8 30.2 41.8 49.2 50.1
74 23.5 34.0 40.8 42.1 23.9 34.7 41.7 43.0 24.2 35.4 42.6 43.9 24.1 35.5 42.8 43.9 24.0 35.5 43.0 43.8
71 - 29.2 35.9 37.2 - 29.5 36.5 37.8 - 29.9 37.1 38.4 - 29.6 36.9 38.0 - 29.3 36.7 37.6
68 - 24.3 31.1 32.4 - 24.3 31.3 32.6 - 24.3 31.5 32.9 - 23.7 31.0 32.1 - 23.0 30.5 31.3
105 °F
NET CAP.
MBH
62.5 57.1 53.0 51.7 63.5 58.0 53.8 52.6 64.5 58.9 54.6 53.4 64.2 58.6 54.3 53.1 63.8 58.2 54.0 52.8
TOTAL POWER
INPUT kW
6.29 6.17 6.12 6.02 6.36 6.24 6.19 6.09 6.43 6.31 6.26 6.16 6.55 6.43 6.38 6.27 6.68 6.55 6.50 6.39
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 41.8 51.8 53.0 51.7 43.6 54.0 53.8 52.6 45.5 56.2 54.6 53.4 47.1 56.7 54.3 56.1 48.7 57.3 54.0 52.8
83 36.9 47.0 52.2
51.7 38.4 48.9 53.4 52.6 39.9 50.7 54.6 53.4 41.2 52.3 54.3 53.1 42.5 53.8 54.0 52.8
80 32.1 42.2 48.5 48.2 33.2 43.7 50.2 49.9 34.4 45.2 52.0 51.6 35.3 46.4 52.4 52.2 36.2 47.6 52.8
52.8
77 27.3 37.3 43.6 43.3 28.1 38.5 45.0 44.7 28.9 39.6 46.4 46.1 29.4 40.5 46.5 46.3 29.9 41.3 46.5 46.5
74 22.4 32.5 38.8 38.5 22.9 33.3 39.8 39.5 23.3 34.1 40.9 40.5 23.5 34.6 40.6 40.4 23.7 35.0 40.3 40.3
71 - 27.6 34.0 33.6 - 28.1 34.6 34.3 - 28.5 35.3 35.0 - 28.7 34.7 34.5 - 28.8 34.0 34.0
68 - 22.8 29.1 28.8 - 22.9 29.5 29.1 - 23.0 29.8 29.4 - 22.8 28.8 28.6 - 22.5 27.8 27.8
115 °F
NET CAP.
MBH
59.0 52.9 49.1 48.2 60.1 53.8 50.0 49.1 61.2 54.8 50.9 50.0 60.7 54.4 50.5 49.6 60.2 54.0 50.1 49.2
TOTAL POWER
INPUT kW
6.92 6.75 6.67 6.67 7.00 6.83 6.75 6.75 7.08 6.90 6.82 6.82 7.25 7.07 6.99 6.99 7.41 7.23 7.15 7.15
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 40.7 50.3 49.1 48.2 42.6 52.6 50.0 49.1 44.6 54.8 50.9 50.0 46.5 54.4 50.5 49.6 48.4 54.0 50.1 49.2
83 35.8 45.4
49.1 48.2 37.4 37.4 50.0 49.1 39.0 49.4 50.9 50.0 40.6 51.3 50.5 49.6 42.2 53.3 50.1 49.2
80 31.0 40.6 46.5 44.6 32.2 42.2 48.4 46.4 33.5 43.8 50.2 48.2 34.7 45.4 50.2 48.7 35.9 47.0
50.1 49.2
77 26.1 35.7 41.7 39.8 27.0 37.0 43.2 41.2 27.9 38.3 44.7 42.6 28.8 39.5 44.3 42.8 29.7 40.8 43.8 43.0
74 21.3 30.9 36.8 34.9 21.8 31.8 38.0 36.0 22.4 32.8 39.2 37.1 22.9 33.6 38.4 36.9 23.4 34.5 37.6 36.7
71 - 26.0 32.0 30.1 - 26.6 32.8 30.8 - 27.2 33.6 31.6 - 27.7 32.5 31.0 - 28.3 31.3 30.5
68 - 21.2 27.1 25.2 - 21.4 27.6 25.6 - 21.7 28.1 26.0 - 21.8 26.6 25.1 - 22.0 25.1 24.2
125 °F
NET CAP.
MBH
55.5 48.7 45.2 44.7 56.7 49.7 46.2 45.7 57.9 50.8 47.2 46.7 57.3 50.2 46.7 46.2 56.7 49.7 46.2 45.7
TOTAL POWER
INPUT kW
7.50 7.30 7.20 7.30 7.60 7.40 7.30 7.40 7.70 7.50 7.40 7.50 7.90 7.70 7.60 7.70 8.20 7.90 7.80 7.90
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 39.6 48.7 45.2 44.7 41.6 51.1 46.2 45.7 43.6 53.5 47.2 46.7 45.9 52.0 46.7 46.2 48.1 50.6 46.2 45.7
83 34.7 43.9
46.0 44.7 36.4 46.0 46.6 45.7 38.1 48.1 47.2 46.7 40.0 50.4 46.7 46.2 41.9 52.8 46.2 45.7
80 29.9 39.0 44.5 41.0 31.2 40.8 46.5 42.9 32.6 42.5 48.5 44.8 34.1 44.5 48.0 45.2 35.6 46.5 47.4
45.7
77 25.0 34.2 39.7 36.2 26.0 35.6 41.3 37.7 27.0 37.0 43.0 39.2 28.2 38.6 42.1 39.3 29.4 40.3 41.1 39.4
74 20.2 29.3 34.8 31.3 20.8 30.4 36.1 32.5 21.5 31.4 37.4 33.7 22.3 32.7 36.2 33.4 23.1 34.0 34.9 33.1
71 - 24.5 30.0 26.5 - 25.2 30.9 27.3 - 25.9 31.9 28.2 - 26.8 30.3 27.5 - 27.7 28.6 26.9
68 - 19.6 25.1 21.7 - 20.0 25.7 22.1 - 20.4 26.4 22.6 - 20.9 24.4 21.6 - 21.5 22.4 20.6
1. These capacities are net capacities (the indoor fan heat is deducted).
ALL SENSIBLE CAPACITY
