ZF180-300 - Hi Static Drive With Powered Convenience Outlet
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA
1
(Amps)
Max Fuse
2
/
Breaker
3
Size
(Amps)
RLA LRA MCC
FLA FLA FLA Model kW Stages Amps
C1 C2 C1 C2 C1 C2
180
(15)
208-3-60 23.3 20.1 190 190 39 35 4.5 15.4 10.0
None - - - 85.9 100
E18 13.5 1 37.5 85.9 100
E36 27.0 2 74.9 125.4 150
E54 40.6 2 112.7 172.6 175
E72 54.1 2 150.2 181.9 200
230-3-60 23.3 20.1 190 190 39 35 4.3 14.4 10.0
None - - - 84.5 100
E18 18.0 1 43.3 84.6 100
E36 36.0 2 86.6 138.8 150
E54 54.0 2 129.9 160.4 175
E72 72.0 2 173.2 203.7 225
460-3-60 11.6 10.9 100 87 19 19 2.2 7.2 5.0
None---43.550
E18 18.0 1 21.7 43.5 50
E36 36.0 2 43.3 69.4 70
E54 54.0 2 65.0 80.2 90
E72 72.0 2 86.6 101.9 110
575-3-60 9.0 8.6 70 62 16 15 1.7 5.9 4.0
None---34.340
E18 18.0 1 17.3 34.3 40
E36 36.0 2 34.6 55.7 60
E54 54.0 2 52.0 64.3 70
E72 72.0 2 69.3 81.7 90
210
(17.5)
208-3-60 27.2 27.2 203 203 42.5 42.5 4.5 20.0 10.0
None - - - 100.2 125
E18 13.5 1 37.5 100.2 125
E36 27.0 2 74.9 131.2 150
E54 40.6 2 112.7 178.4 200
E72 54.1 2 150.2 187.7 200
230-3-60 27.2 27.2 203 203 42.5 42.5 4.3 20.0 10.0
None - - - 99.8 125
E18 18.0 1 43.3 99.8 125
E36 36.0 2 86.6 145.8 150
E54 54.0 2 129.9 167.4 175
E72 72.0 2 173.2 210.7 225
460-3-60 15.1 15.1 92 92 22 22 2.2 10.0 5.0
None---53.460
E18 18.0 1 21.7 53.4 60
E36 36.0 2 43.3 72.9 80
E54 54.0 2 65.0 83.7 90
E72 72.0 2 86.6 105.4 110
575-3-60 11.6 11.6 84 84 18 18 1.7 8.2 4.0
None---41.750
E18 18.0 1 17.3 41.7 50
E36 36.0 2 34.6 58.6 60
E54 54.0 2 52.0 67.2 70
E72 72.0 2 69.3 84.5 90
240
(20)
208-3-60 42.9 42.9 267 267 62.9 62.9 4.5 20.0 10.0
None - - - 135.5 175
E18 13.5 1 37.5 135.5 175
E36 27.0 2 74.9 135.5 175
E54 40.6 2 112.7 178.4 200
E72 54.1 2 150.2 187.7 200
230-3-60 42.9 42.9 267 267 62.9 62.9 4.3 20.0 10.0
None - - - 135.1 175
E18 18.0 1 43.3 135.1 175
E36 36.0 2 86.6 145.8 175
E54 54.0 2 129.9 167.4 175
E72 72.0 2 173.2 210.7 225
460-3-60 18.5 18.5 130 130 29 29 2.2 10.0 5.0
None---61.070
E18 18.0 1 21.7 61.0 70
E36 36.0 2 43.3 72.9 80
E54 54.0 2 65.0 83.7 90
E72 72.0 2 86.6 105.4 110
575-3-60 15.3 15.3 114 114 24 24 1.7 8.2 4.0
None---50.060
E18 18.0 1 17.3 50.0 60
E36 36.0 2 34.6 58.6 60
E54 54.0 2 52.0 67.2 70
E72 72.0 2 69.3 84.5 90
