251934-YTG-J-0910
Johnson Controls Unitary Products 41
ZF180-300 Cooling Capacities
ZF180 (15 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
3750
77 236.7 12.4 97.3 80.1 63.0 - - - 223.9 13.0 91.7 74.8 58.0 - - -
72 216.0 11.9 124.5 107.3 90.2 73.1 - - 204.1 12.8 119.4 102.5 85.7 68.8 - -
67 195.4 11.5 151.7 134.6 117.4 100.3 83.1 - 184.4 12.7 147.0 130.2 113.3 96.5 79.7 -
62 178.4 11.3 178.4 164.0 142.0 124.9 107.7 90.6 168.9 12.4 168.9 161.1 137.2 120.3 103.5 86.6
4500
77 245.7 12.5 107.4 88.5 69.5 - - - 232.3 13.1 101.7 82.8 63.9 - - -
72 224.3 12.0 137.4 118.5 99.5 80.6 - - 211.9 12.9 132.2 113.3 94.5 75.6 - -
67 202.8 11.6 167.4 148.5 129.6 110.6 91.7 - 191.4 12.7 162.7 143.9 125.0 106.1 87.2 -
62 185.2 11.3 185.2 175.6 156.7 137.8 118.8 99.9 175.3 12.5 175.3 170.1 151.2 132.4 113.5 94.6
57 236.4 10.9 236.4 231.9 213.0 194.0 175.1 156.2 201.8 12.3 201.8 199.2 180.3 161.4 142.6 123.7
5250
77 254.6 12.5 117.5 96.8 76.0 - - - 240.8 13.2 111.7 90.8 69.9 - - -
72 232.5 12.1 150.3 129.6 108.9 88.2 - - 219.6 13.0 145.1 124.2 103.3 82.4 - -
67 210.3 11.6 183.2 162.5 141.7 121.0 100.3 - 198.4 12.8 178.4 157.5 136.6 115.7 94.8 -
62 192.0 11.4 192.0 187.2 171.4 150.7 129.9 109.2 181.7 12.6 181.7 179.1 165.3 144.4 123.5 102.6
57 245.1 10.9 245.1 242.8 232.9 212.2 191.4 170.7 209.1 12.4 209.1 207.8 197.1 176.2 155.3 134.4
6000
77 263.6 12.6 127.6 105.1 82.6 - - - 249.3 13.2 121.7 98.8 75.9 - - -
72 240.7 12.2 163.3 140.7 118.2 95.7 - - 227.3 13.1 157.9 135.0 112.1 89.1 - -
67 217.7 11.7 198.9 176.4 153.9 131.4 108.8 - 205.4 12.9 194.1 171.2 148.3 125.3 102.4 -
62 198.8 11.5 198.8 198.8 186.1 163.6 141.0 118.5 188.1 12.7 188.1 188.1 179.4 156.5 133.6 110.6
57 253.7 11.0 253.7 253.7 252.8 230.3 207.8 185.3 216.5 12.4 216.5 216.5 213.9 191.0 168.0 145.1
6750
72 246.2 12.1 172.9 148.2 123.5 98.8 - - 231.1 13.1 168.9 144.1 119.2 94.4 - -
67 222.7 11.7 213.3 185.4 160.7 136.0 111.3 - 208.8 12.9 203.2 182.6 157.7 132.9 108.0 -
62 203.4 11.5 203.4 203.4 197.0 172.3 147.6 122.9 191.2 12.7 191.2 191.2 186.9 162.0 137.2 112.3
57 259.3 11.0 259.3 259.3 258.8 234.1 209.4 184.7 220.1 12.5 220.1 220.1 218.8 193.9 169.1 144.2
7500
72 251.8 12.1 182.6 155.7 128.8 101.9 - - 234.9 13.1 180.0 153.2 126.4 99.6 - -
67 227.8 11.7 227.8 194.4 167.5 140.6 113.7 - 212.2 12.9 212.2 194.0 167.2 140.4 113.6 -
62 208.0 11.4 208.0 208.0 208.0 181.1 154.2 127.3 194.3 12.7 194.3 194.3 194.3 167.5 140.7 113.9
57 264.8 11.0 264.8 264.8 264.8 237.9 211.0 184.2 223.7 12.5 223.7 223.7 223.7 196.9 170.1 143.3
95°F 105°F
3750
77 211.0 13.6 86.1 69.5 53.0 - - - 197.0 15.4 81.3 67.6 51.0 - - -
72 192.2 13.7 114.2 97.7 81.1 64.6 - - 179.3 15.4 111.5 94.9 78.3 61.7 - -
67 173.4 13.8 142.4 125.8 109.3 92.7 76.2 - 161.6 15.3 141.8 122.2 105.6 88.9 72.3 -
62 159.3 13.6 159.3 158.2 132.3 115.8 99.2 82.7 148.6 15.1 148.6 144.5 120.5 103.9 87.3 70.6
4500
77 219.0 13.7 96.0 77.2 58.4 - - - 204.0 15.5 93.6 74.8 56.0 - - -
72 199.5 13.8 127.0 108.2 89.4 70.6 - - 185.7 15.4 123.6 104.8 86.0 67.2 - -
67 180.0 13.9 158.0 139.2 120.4 101.6 82.8 - 167.4 15.4 153.5 134.7 115.9 97.1 78.3 -
62 165.4 13.7 165.4 164.6 145.8 127.0 108.2 89.4 153.9 15.2 153.9 151.2 132.4 113.5 94.7 75.9
57 167.1 13.7 167.1 166.4 147.6 128.8 110.0 91.2 157.6 15.2 157.6 157.3 139.5 120.7 101.9 83.1
5250
77 227.0 13.8 105.9 84.9 63.8 - - - 211.0 15.5 106.0 82.0 61.0 - - -
72 206.7 13.9 139.8 118.7 97.7 76.6 - - 192.0 15.5 135.6 114.6 93.6 72.6 - -
67 186.5 14.0 173.7 152.6 131.5 110.5 89.4 - 173.1 15.4 165.2 147.2 126.2 105.3 84.3 -
62 171.4 13.8 171.4 171.0 159.3 138.2 117.1 96.1 159.1 15.2 159.1 157.8 144.2 123.2 102.2 81.2
57 173.2 13.8 173.2 172.8 161.3 140.2 119.1 98.1 163.0 15.3 163.0 162.8 152.0 131.0 110.0 89.0
6000
77 234.9 13.8 115.9 92.5 69.2 - - - 217.9 15.6 118.4 89.2 66.0 - - -
72 214.0 13.9 152.6 129.3 105.9 82.6 - - 198.4 15.5 147.7 124.5 101.3 78.1 - -
67 193.1 14.1 189.3 166.0 142.7 119.3 96.0 - 178.8 15.5 177.0 159.8 136.6 113.4 90.2 -
62 177.4 13.8 177.4 177.4 172.8 149.4 126.1 102.8 164.4 15.3 164.4 164.4 156.0 132.9 109.7 86.5
57 179.3 13.9 179.3 179.3 174.9 151.6 128.3 104.9 168.4 15.3 168.4 168.4 164.4 141.3 118.1 94.9
6750
72 216.0 14.0 165.0 140.0 114.9 89.9 - - 200.1 15.5 159.0 134.2 109.5 84.7 - -
67 194.8 14.1 193.0 179.8 154.8 129.8 104.8 - 180.4 15.5 179.5 170.1 147.6 122.8 98.1 -
62 179.0 13.9 179.0 179.0 176.7 151.7 126.7 101.7 165.9 15.3 165.9 165.9 161.7 136.9 112.1 87.4
57 180.9 13.9 180.9 180.9 178.8 153.7 128.7 103.7 169.9 15.4 169.9 169.9 167.9 143.1 118.4 93.6
7500
72 217.9 14.0 177.4 150.6 123.9 97.2 - - 201.9 15.6 170.4 144.0 117.6 91.3 - -
67 196.6 14.1 196.6 193.6 166.9 140.2 113.5 - 182.0 15.5 182.0 180.5 158.6 132.2 105.9 -
62 180.7 13.9 180.7 180.7 180.7 154.0 127.3 100.5 167.3 15.3 167.3 167.3 167.3 140.9 114.6 88.2
57 182.6 14.0 182.6 182.6 182.6 155.9 129.2 102.4 171.4 15.4 171.4 171.4 171.4 145.0 118.6 92.3
