ZF180 - 300
ZF180-300 - Standard Drive Without Powered Convenience Outlet
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA
1
(Amps)
Max Fuse
2
/
Breaker
3
Size
(Amps)
RLA LRA MCC
FLA FLA FLA Model kW Stages Amps
C1 C2 C1 C2 C1 C2
180
(15)
208-3-60 23.3 20.1 190 190 39 35 4.5 15.4 0.0
None---75.990
E18 13.5 1 37.5 75.9 90
E36 27.0 2 74.9 112.9 125
E54 40.6 2 112.7 160.1 175
E72 54.1 2 150.2 169.4 200
230-3-60 23.3 20.1 190 190 39 35 4.3 14.4 0.0
None---74.590
E18 18.0 1 43.3 74.5 90
E36 36.0 2 86.6 126.3 150
E54 54.0 2 129.9 147.9 175
E72 72.0 2 173.2 191.2 225
460-3-60 11.6 10.9 100 87 19 19 2.2 7.2 0.0
None---38.550
E18 18.0 1 21.7 38.5 50
E36 36.0 2 43.3 63.1 70
E54 54.0 2 65.0 74.0 90
E72 72.0 2 86.6 95.6 110
575-3-60 9.0 8.6 70 62 16 15 1.7 5.9 0.0
None---30.335
E18 18.0 1 17.3 30.3 35
E36 36.0 2 34.6 50.7 60
E54 54.0 2 52.0 59.3 70
E72 72.0 2 69.3 76.7 90
210
(17.5)
208-3-60 27.2 27.2 203 203 42.5 43 4.5 15.4 0.0
None - - - 85.6 110
E18 13.5 1 37.5 85.6 110
E36 27.0 2 74.9 112.9 125
E54 40.6 2 112.7 160.1 175
E72 54.1 2 150.2 169.4 200
230-3-60 27.2 27.2 203 203 42.5 43 4.3 14.4 0.0
None - - - 84.2 110
E18 18.0 1 43.3 84.2 110
E36 36.0 2 86.6 126.3 150
E54 54.0 2 129.9 147.9 175
E72 72.0 2 173.2 191.2 225
460-3-60 15.1 15.1 92 92 22 22 2.2 7.2 0.0
None---45.660
E18 18.0 1 21.7 45.6 60
E36 36.0 2 43.3 63.1 70
E54 54.0 2 65.0 74.0 90
E72 72.0 2 86.6 95.6 110
575-3-60 11.6 11.6 84 84 18 18 1.7 5.9 0.0
None---35.445
E18 18.0 1 17.3 35.4 45
E36 36.0 2 34.6 50.7 60
E54 54.0 2 52.0 59.3 70
E72 72.0 2 69.3 76.7 90
240
(20)
208-3-60 42.9 42.9 267 267 62.9 63 4.5 15.4 0.0
None - - - 120.9 150
E18 13.5 1 37.5 120.9 150
E36 27.0 2 74.9 120.9 150
E54 40.6 2 112.7 160.1 175
E72 54.1 2 150.2 169.4 200
230-3-60 42.9 42.9 267 267 62.9 63 4.3 14.4 0.0
None - - - 119.5 150
E18 18.0 1 43.3 119.5 150
E36 36.0 2 86.6 126.3 150
E54 54.0 2 129.9 147.9 175
E72 72.0 2 173.2 191.2 225
460-3-60 18.5 18.5 130 130 29 29 2.2 7.2 0.0
None---53.270
E18 18.0 1 21.7 53.2 70
E36 36.0 2 43.3 63.1 70
E54 54.0 2 65.0 74.0 90
E72 72.0 2 86.6 95.6 110
575-3-60 15.3 15.3 114 114 24 24 1.7 5.9 0.0
None---43.750
E18 18.0 1 17.3 43.7 50
E36 36.0 2 34.6 50.7 60
E54 54.0 2 52.0 59.3 70
E72 72.0 2 69.3 76.7 90
