251934-YTG-J-0910
Johnson Controls Unitary Products 25
ZJ240 (20 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Total
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
5000
77 312.8 14.5 131.5 108.5 85.8 - - - 296.3 16.3 127.4 104.6 81.9 - - -
72 286.7 14.3 169.5 146.7 124.0 101.2 - - 272.0 16.2 164.1 141.3 118.5 95.7 - -
67 260.5 14.1 207.5 184.9 162.2 139.4 116.7 - 247.7 16.0 200.8 178.0 155.2 132.4 109.6 -
62 241.1 13.9 241.1 223.6 195.3 172.5 149.8 127.0 232.5 15.8 232.5 218.9 187.9 165.1 142.3 119.5
6000
77 326.2 14.6 145.7 119.9 94.0 - - - 306.7 16.4 141.3 115.5 89.6 - - -
72 298.9 14.4 187.6 161.7 135.8 110.0 - - 281.5 16.3 181.5 155.6 129.8 104.0 - -
67 271.6 14.2 229.4 203.5 177.7 151.8 125.9 - 256.3 16.1 221.6 195.8 169.9 144.1 118.3 -
62 251.5 14.0 251.5 239.8 213.9 188.1 162.2 136.3 240.7 15.9 240.7 231.6 205.7 179.9 154.1 128.2
57 244.1 14.1 244.1 244.4 221.2 195.3 169.5 143.6 235.2 16.0 235.2 235.2 210.7 184.9 159.0 133.2
7000
77 339.6 14.7 160.0 131.2 102.2 - - - 317.0 16.5 155.2 126.3 97.4 - - -
72 311.2 14.5 205.7 176.7 147.7 118.7 - - 291.0 16.3 198.8 170.0 141.1 112.2 - -
67 282.8 14.3 251.4 222.2 193.2 164.2 135.2 - 265.0 16.2 242.5 213.6 184.7 155.8 127.0 -
62 261.9 14.1 261.9 256.0 232.6 203.6 174.7 145.7 248.8 16.0 248.8 244.2 223.6 194.7 165.9 137.0
57 254.2 14.2 254.2 254.3 240.5 211.5 182.5 153.6 243.2 16.1 243.2 243.2 229.0 200.1 171.3 142.4
8000
77 353.0 14.8 174.2 142.5 110.4 - - - 327.4 16.5 169.1 137.1 105.2 - - -
72 323.5 14.6 223.8 191.7 159.6 127.5 - - 300.5 16.4 216.2 184.3 152.4 120.4 - -
67 294.0 14.3 273.3 240.8 208.7 176.6 144.5 - 273.7 16.3 263.3 231.4 199.5 167.6 135.6 -
62 272.2 14.2 272.2 272.2 251.3 219.2 187.1 155.0 256.9 16.1 256.9 256.9 241.5 209.6 177.7 145.7
57 264.3 14.3 264.3 264.3 259.8 227.7 195.6 163.5 251.1 16.2 251.1 251.1 247.3 215.4 183.5 151.6
8700
72 330.8 14.5 233.9 199.7 165.5 131.3 - - 308.6 16.4 227.1 193.0 158.9 124.8 - -
67 300.6 14.3 290.3 250.7 216.5 182.3 148.2 - 281.0 16.2 275.9 242.1 208.0 174.0 139.9 -
62 278.4 14.2 278.4 278.4 260.7 226.5 192.3 158.2 263.8 16.0 263.8 263.8 251.9 217.8 183.7 149.6
57 270.2 14.3 270.2 270.2 268.0 233.8 199.6 165.5 257.9 16.1 257.9 257.9 256.0 221.9 187.8 153.7
9400
72 338.1 14.5 243.9 207.7 171.5 135.2 - - 316.7 16.3 237.9 201.7 165.4 129.2 - -
67 307.3 14.3 307.3 260.5 224.3 188.0 151.8 - 288.4 16.2 288.4 252.8 216.6 180.3 144.1 -
62 284.5 14.1 284.5 284.5 270.0 233.8 197.6 161.3 270.8 16.0 270.8 270.8 262.2 226.0 189.7 153.4
57 276.1 14.3 276.1 276.1 276.1 239.9 203.7 167.4 264.6 16.1 264.6 264.6 264.6 228.4 192.1 155.9
95°F 105°F
5000
77 279.8 18.1 123.4 100.8 77.9 - - - 266.3 20.4 113.1 96.4 73.6 - - -
72 257.3 18.0 158.7 135.9 113.1 90.2 - - 242.4 20.3 153.2 130.4 107.6 84.9 - -
67 234.9 18.0 194.1 171.0 148.2 125.4 102.5 - 218.6 20.3 193.2 164.4 141.7 118.9 96.1 -
62 224.0 17.7 224.0 214.2 180.5 157.6 134.8 112.0 209.6 20.1 209.6 204.7 170.6 147.8 125.0 102.3
6000
77 287.1 18.1 136.9 111.1 85.3 - - - 272.9 20.5 132.5 106.6 80.7 - - -
72 264.1 18.1 175.4 149.6 123.8 98.0 - - 248.5 20.4 169.8 143.9 118.0 92.1 - -
67 241.0 18.1 213.8 188.0 162.2 136.4 110.6 - 224.1 20.3 207.1 181.2 155.4 129.5 103.6 -
62 229.9 17.8 229.9 223.3 197.5 171.7 145.9 120.1 214.8 20.1 214.8 211.6 187.1 161.2 135.3 109.4
57 226.4 17.9 226.4 226.0 200.2 174.4 148.6 122.8 212.7 20.2 212.7 212.5 187.7 161.8 136.0 110.1
7000
77 294.4 18.2 150.4 121.4 92.7 - - - 279.5 20.5 151.8 116.8 87.8 - - -
72 270.8 18.2 192.0 163.2 134.5 105.7 - - 254.5 20.5 186.4 157.4 128.4 99.4 - -
67 247.2 18.1 233.6 205.0 176.2 147.5 118.7 - 229.5 20.4 221.1 198.1 169.1 140.1 111.0 -
62 235.7 17.9 235.7 232.5 214.6 185.8 157.1 128.3 220.1 20.2 220.1 218.4 203.5 174.5 145.5 116.5
57 232.1 17.9 232.1 232.0 217.5 188.7 160.0 131.2 217.8 20.2 217.8 217.7 204.3 175.3 146.3 117.3
8000
77 301.7 18.3 163.9 131.8 100.0 - - - 286.2 20.6 171.2 127.1 94.9 - - -
72 277.5 18.3 208.6 176.9 145.2 113.4 - - 260.6 20.5 203.1 171.0 138.8 106.7 - -
67 253.3 18.2 253.3 222.0 190.3 158.5 126.8 - 235.0 20.4 235.0 214.9 182.8 150.6 118.5 -
62 241.6 18.0 241.6 241.6 231.7 199.9 168.2 136.5 225.3 20.2 225.3 225.3 220.0 187.9 155.8 123.7
57 237.9 18.0 237.9 237.9 234.8 203.1 171.3 139.6 223.0 20.3 223.0 223.0 220.8 188.7 156.6 124.5
8700
72 286.4 18.2 220.3 186.3 152.3 118.3 - - 268.6 20.5 214.5 180.2 145.9 111.6 - -
67 261.5 18.2 261.5 233.6 199.6 165.6 131.6 - 242.2 20.4 242.2 226.0 192.0 157.7 123.4 -
62 249.3 17.9 249.3 249.3 243.0 209.0 175.0 141.0 232.2 20.2 232.2 232.2 228.9 194.6 160.3 126.0
57 245.5 18.0 245.5 245.5 244.0 210.0 176.0 142.0 229.8 20.2 229.8 229.8 228.7 194.4 160.1 125.8
9400
72 295.3 18.1 231.9 195.7 159.4 123.1 - - 276.5 20.4 225.9 189.4 152.9 116.4 - -
67 269.6 18.1 269.6 245.2 208.9 172.6 136.4 - 249.4 20.3 249.4 237.2 201.3 164.8 128.3 -
62 257.1 17.9 257.1 257.1 254.4 218.1 181.8 145.6 239.1 20.2 239.1 239.1 237.8 201.3 164.8 128.3
57 253.1 17.9 253.1 253.1 253.1 216.9 180.6 144.3 236.7 20.2 236.7 236.7 236.7 200.2 163.7 127.2
