Performance Water-Cooled
Data
PKG-PRC002-EN44
Table PD-21. SCWF/SIWF 38 - Economizer Low Capacity - 15,200 cfm
Entering Water Temp
Entering Air 45 F 55 F
EDB EWB Flow Total Sensible LWT Total Sensible LWT
F F gpm MBh MBh F MBh MBh F
95 228.0 219.3 49.8 151.4 151.4 58.2
62 114 237.0 228.2 49.2 155.9 155.9 57.7
119 239.0 238.1 49.0 156.9 156.9 57.6
95 288.5 190.0 51.1 165.1 145.8 58.5
75 67 114 305.2 196.3 50.4 173.1 148.5 58.0
119 308.9 197.7 50.2 175.0 149.2 57.9
95 368.4 149.1 52.8 239.5 106.0 60.0
72 114 390.3 156.8 51.8 254.0 110.7 59.5
119 395.3 158.6 51.6 257.3 111.8 59.3
95 262.3 262.3 50.5 189.2 189.2 59.0
62 114 270.4 270.4 49.7 194.9 194.9 58.4
119 272.2 272.2 49.6 196.1 196.1 58.3
95 290.0 247.8 51.1 189.5 189.5 59.0
80 67 114 305.3 253.5 50.4 195.2 185.9 58.4
119 308.8 254.8 50.2 196.5 187.2 58.3
95 367.6 206.3 52.7 238.7 163.2 60.0
72 114 389.5 213.9 51.8 253.2 167.9 59.4
119 394.5 215.7 51.6 256.4 168.9 59.3
95 299.8 299.8 51.3 227.1 227.1 59.8
62 114 309.1 309.1 50.4 233.8 233.8 59.1
119 311.1 311.1 50.2 235.3 235.3 59.0
95 305.9 296.1 51.4 227.5 227.5 59.8
85 67 114 318.2 315.4 50.6 234.2 234.2 59.1
119 321.0 316.5 50.4 235.7 235.7 59.0
95 366.9 263.3 52.7 244.3 222.3 60.1
72 114 388.7 270.9 51.8 256.2 226.2 59.5
119 393.6 272.7 51.6 259.0 227.1 59.4
Table PD-20. SCWF/SIWF 38 - Economizer Full Capacity - 15,200 cfm
Entering Air 45 F 55 F
EDB EWB Flow Total Sensible LWT Total Sensible LWT
F F gpm MBh MBh F MBh MBh F
95 355.5 330.9 52.5 226.5 226.5 59.8
62 114 370.6 337.2 51.5 232.7 232.7 59.1
119 374.1 338.7 51.3 234.0 234.0 58.9
95 450.7 277.7 54.5 260.8 207.6 60.5
75 67 114 478.7 288.7 53.4 274.4 212.4 59.8
119 485.0 291.2 53.2 277.6 213.5 59.7
95 576.2 229.0 57.1 374.4 159.1 62.9
72 114 613.4 242.7 55.8 399.7 167.5 62.0
119 621.8 245.8 55.4 405.4 169.4 61.8
95 394.0 385.2 53.3 283.0 283.0 61.0
62 114 405.8 397.1 52.1 290.7 290.7 60.1
119 408.5 399.7 51.9 292.4 292.4 59.9
95 457.8 356.0 54.6 289.1 279.0 61.1
80 67 114 482.4 365.7 53.5 299.5 296.9 60.3
119 488.0 367.9 53.2 301.8 297.8 60.1
95 574.9 304.5 57.1 374.0 235.0 62.9
72 114 612.0 318.2 55.7 398.4 243.1 62.0
119 620.3 321.3 55.4 404.0 245.0 61.8
95 449.7 449.7 54.5 339.5 339.5 62.1
62 114 462.2 462.2 53.1 348.7 348.7 61.1
119 464.8 464.8 52.8 350.7 350.7 60.9
95 478.6 439.4 55.1 340.5 340.5 62.2
85 67 114 499.4 447.7 53.8 349.7 349.7 61.1
119 504.2 449.6 53.5 351.7 351.7 60.9
95 575.8 380.7 57.1 386.7 315.1 63.1
72 114 611.1 393.6 55.7 407.1 321.9 62.1
119 619.2 396.6 55.4 411.8 323.5 61.9
38 Ton
