19
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
4. Place the center log piece over the corresponding pins next to the
front left log as shown in Figure 23.
Center
Log
Piece
Figure 23
Center
Top Twig
7. Install the center top twig onto the corresponding pin on the rear
log and align it with the indentation on front left log as shown in
Figure 26.
Figure 26
Figure 25
Left Top Twig
Right Front Log
Figure 24
5. Install the right front log onto the corresponding burner pin and
sub-floor right tab as shown in Figure 24.
6. Install the left top twig onto the corresponding pin on the rear
log and align it with the indentation on the front left log as shown
in Figure 25.
Rear
Log
Figure 21
3. Place the left front log onto the corresponding burner pin and
sub-floor left tab as shown in Figure 22.
Note: If an optional Brick Liner Kit was purchased, install it now, per instruc-
tions provided in kit
2. Place the largest log onto the rear log stoppers (see Figure 20).
Ensure that the grooves on the bottom of the log aligns onto the cor-
responding places on the rear log stoppers. Push the log back so that
it is against the back of the rear log stoppers (see Figure 21).
Left Front Log
Figure 22
