Janome 4800 Sewing Machine User Manual



33
Sewing Buttons
1 Stitch pattern: 05
2 Presser foot: Satin stitch foot F
3 Feed dogs: Down
[1] Turn the handwheel by hand five times and raise the
needle to the highest point.
Match the holes on the button to the horizontal slot
on
the presser foot.
Lower the foot to hold the button in place.
Lower the feed dogs.
Press the stitch width button “+” or “-” so the needle
will enter the left hole of the button.
Turn the handwheel so the needle will enter the right
hole of the button.
* Readjust the stitch width if necessary.
[2] Place a pin on the foot and stitch ten times.
After you finish sewing, cut the thread but leave 20
cm(8 “) of thread on the wrong side of the fabric.
1 Pin
[3] Draw the thread to the wrong side of the fabric and
knot the threads.
Note: When sewing on the button is completed, raise
the feed dogs.
The feed dogs must always be up for normal
sewing.
2 Upper thread
3 Lower thread
4 Shank
5 Fabric
12
1
2
3
4
5
[1]
[2]
[3]
3
