17
• Winding the bobbin
For the bobbin winding, set the speed control lever at
the medium to high speed position.
[1] Hold the end of thread.
[2] Guide the thread through the thread guide “A”.
[3] Thread the thread guide “B”.
[4] Thread the thread guide “C”.
[5] Thread through the hole in the bobbin from the
inside to the outside.
1 Bobbin winder spindle
[6] Put the bobbin on the bobbin winder spindle, and
push it to the right.
2 Bobbin winder stopper
[7] Hold the free end of the thread in your hand and
depress the foot control.
Stop the machine when it has made a few turns,
and cut the thread close to the hole in the bobbin.
Depress the foot control again.
When the bobbin is fully wound, it will stop
automatiaclly.
, Return the bobbin winder to its original position by
moving the spindle to the left, and cut the thread as
shown.
* The machine will not sew until the spindle is in the
left position.
* You can also use the additional spool pin for the
bobbin winding as shown.
3 Spool
4 Additional spool pin
5 Felt
6 Additional spool pin hole
7 Spool base
[1]
[2]
[4]
[3]
[5]
[6]
[7]
,
3
5
4
7
6
1
6
2
“A”
“B”
“C”
