Various Utility Stitches
• Basting
1
Stitch pattern : 24
2 Presser foot: Basting foot P
3 Thread tension dial : 1 to 4
4 Feed dogs : Down
* Set the manual thread tension at “1 to 4”.
Attaching the basting foot:
[1]Raise the needle.
[2] Remove the foot holder by loosening the thumb
screw.
[3]Attach the basting foot on the presser bar putting the
pin on the needle clamp.
Tighten the thumb screw firmly with a large
screwdriver.
1 Foot holder
2 Thumb screw
3 Pin
4 Needle clamp
How to sew
[1]Put some fabric under the foot and press the Up/
down needle button twice to bring the needle thread
down through the hole in the foot. Pull the fabric and
thread to the rear. Lower the presser foot.
[2]While pressing down the foot control, hold the fabric
taut.
[3]When the machine is stopped after one stitch sewing,
pull the fabric with the thread to the back.
[4]Repeat steps 2 and 3 to sew. After finishing sewing,
pull the threads and fabric to the back and cut the
threads.
* After sewing, reset the thread tension dial at “AUTO “
and raise the feed dogs, slide the drop feed lever to
theleft.
1
3
2
4
1
2
3
2
4
[1]
[2]
[1]
[2]
[3] [4]
[3]
