COOLING PERFORMANCE DATA
GSX130481A*
EXPANDED PERFORMANCE DATA
COOLING OPERATION
MODEL: GSX13048-1A* / CA*F4860*6** / ZP39K5E-PFV
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 596367715963677159 63 677159 63 67 715963677159636771
MBh 45.1 46.7 51.2 - 44.0 45.6 50.0 - 43.0 44.5 48.8 - 41.9 43.5 47.6 - 39.8 41.3 45.2 - 36.9 38.2 41.9 -
S/T 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.86 0.72 0.50 - 0.86 0.72 0.50 -
Delta T 17 15 11 - 18 15 12 - 18 15 12 - 18 15 12 - 17 15 11 - 16 14 11 -
1800 KW 3.16 3.22 3.33 - 3.40 3.48 3.59 - 3.62 3.70 3.83 - 3.82 3.90 4.03 - 3.98 4.07 4.21 - 4.12 4.22 4.36 -
AMPS 11.6 11.9 12.3 - 12.5 12.9 13.3 - 13.7 14.0 14.5 - 14.6 15.0 15.5 - 15.6 16.0 16.5 - 16.5 17.0 17.5 -
HI PR 236 253 268 - 264 284 300 - 301 323 342 - 342 368 389 - 385 414 438 - 425 458 484 -
LO PR 110 117 128 - 116 124 135 - 121 129 140 - 127 135 147 - 133 142 155 - 138 146 160 -
MBh 43.8 45.4 49.7 - 42.7 44.3 48.5 - 41.7 43.2 47.4 - 40.7 42.2 46.2 - 38.7 40.1 43.9 - 35.8 37.1 40.7 -
S/T 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.82 0.69 0.48 -
Delta T 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -
70 1600 KW 3.13 3.20 3.30 - 3.38 3.45 3.56 - 3.59 3.67 3.80 - 3.79 3.87 4.00 - 3.95 4.04 4.17 - 4.09 4.18 4.32 -
AMPS 11.5 11.8 12.1 - 12.4 12.7 13.2 - 13.5 13.9 14.3 - 14.5 14.8 15.4 - 15.4 15.8 16.4 - 16.4 16.8 17.4 -
HI PR 233 251 265 - 262 282 297 - 298 320 338 - 339 365 385 - 381 410 433 - 421 453 479 -
LO PR 109 116 127 - 115 123 134 - 120 127 139 - 126 134 146 - 132 140 153 - 136 145 158 -
MBh 40.4 41.9 45.9 - 39.5 40.9 44.8 - 38.5 39.9 43.7 - 37.6 38.9 42.7 - 35.7 37.0 40.5 - 33.1 34.3 37.5 -
S/T 0.69 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.61 0.43 - 0.76 0.63 0.44 - 0.79 0.66 0.46 - 0.80 0.66 0.46 -
Delta T 18 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -
1400 KW 3.05 3.12 3.22 - 3.29 3.37 3.47 - 3.50 3.58 3.70 - 3.69 3.77 3.90 - 3.85 3.93 4.07 - 3.98 4.07 4.21 -
AMPS 11.2 11.4 11.8 - 12.1 12.4 12.8 - 13.1 13.5 13.9 - 14.1 14.4 14.9 - 15.0 15.4 15.9 - 15.9 16.3 16.9 -
HI PR 226 243 257 - 254 273 288 - 289 311 328 - 329 354 374 - 370 398 420 - 409 440 464 -
LO PR 106 112 123 - 112 119 130 - 116 124 135 - 122 130 142 - 128 136 148 - 132 141 154 -
MBh 45.8 47.2 51.1 54.8 44.8 46.1 49.9 53.6 43.7 45.0 48.7 52.3 42.6 43.9 47.5 51.0 40.5 41.7 45.1 48.5 37.5 38.6 41.8 44.9
S/T 0.86 0.77 0.58 0.37 0.89 0.79 0.60 0.39 0.91 0.81 0.62 0.40 0.94 0.84 0.64 0.41 0.97 0.87 0.66 0.42 0.98 0.88 0.67 0.43
Delta T201815102019151120 19 151120 19 15 11 20 19 15 11 19 17 14 10
1800 KW 3.18 3.25 3.36 3.47 3.43 3.51 3.62 3.75 3.65 3.74 3.86 3.99 3.85 3.94 4.07 4.21 4.02 4.11 4.25 4.39 4.16 4.26 4.40 4.55
AMPS 11.7 12.0 12.4 12.9 12.7 13.0 13.4 13.9 13.8 14.1 14.6 15.2 14.8 15.1 15.6 16.3 15.7 16.1 16.7 17.3 16.7 17.1 17.7 18.4
HI PR 238 256 270 282 267 287 303 316 304 327 345 360 346
372
393 410 389 419 442 461 430 463 488 509
LO PR 111 118 129 138 118 125 136 145 122 130 142 151 128 136 149 159 134 143 156 166 139 148 161 172
MBh 44.5 45.8 49.6 53.2 43.5 44.8 48.4 52.0 42.4 43.7 47.3 50.8 41.4 42.6 46.1 49.5 39.3 40.5 43.8 47.0 36.4 37.5 40.6 43.6
S/T 0.82 0.73 0.55 0.36 0.85 0.76 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93 0.83 0.63 0.40 0.94 0.84 0.63 0.41
Delta T211916112119161121 19 161121 20 16 11 21 19 16 11 20 18 15 10
75 1600 KW 3.16 3.22 3.33 3.44 3.40 3.48 3.59 3.71 3.62 3.71 3.83 3.96 3.82 3.90 4.04 4.17 3.98 4.07 4.21 4.36 4.12 4.22 4.36 4.51
AMPS 11.6 11.9 12.3 12.7 12.5 12.9 13.3 13.8 13.7 14.0 14.5 15.0 14.6 15.0 15.5 16.1 15.6 16.0 16.5 17.2 16.5 17.0 17.5 18.2
HI PR 236 253 268 279 264 284 300 313 301 323 342 356 342
368
389 406 385 415 438 457 426 458 484 504
LO PR 110 117 128 136 116 124 135 144 121 129 140 150 127 135 148 157 133 142 155 165 138 146 160 170
MBh 41.1 42.3 45.8 49.1 40.1 41.3 44.7 48.0 39.2 40.3 43.7 46.8 38.2 39.3 42.6 45.7 36.3 37.4 40.5 43.4 33.6 34.6 37.5 40.2
S/T 0.79 0.70 0.53 0.34 0.82 0.73 0.55 0.36 0.84 0.75 0.57 0.36 0.86 0.77 0.58 0.38 0.90 0.80 0.61 0.39 0.90 0.81 0.61 0.39
Delta T212016112220161122 20 161122 20 16 11 21 20 16 11 20 18 15 10
1400 KW 3.08 3.15 3.25 3.35 3.32 3.39 3.50 3.62 3.53 3.61 3.73 3.86 3.72 3.80 3.93 4.07 3.88 3.97 4.10 4.24 4.02 4.11 4.25 4.40
AMPS 11.3 11.5 11.9 12.4 12.2 12.5 12.9 13.4 13.3 13.6 14.1 14.6 14.2 14.6 15.1 15.6 15.1 15.5 16.1 16.7 16.1 16.5 17.0 17.7
HI PR 228 246 260 271 256 276 291 304 292 314 331 346 332
357
377 394 374 402 425 443 413 444 469 489
LO PR 107 114 124 132 113 120 131 140 117 125 136 145 123 131 143 152 129 137 150 160 134 142 155 165
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ACCA (TVA) conditions
