COOLING PERFORMANCE DATA
GSX130181A*
EXPANDED PERFORMANCE DATA
COOLING OPERATION
MODEL: GSX130181A* / CA*F1824*6** / ZP16K5E-PFV
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
MBh 17.6 18.3 20.0 - 17.2 17.9 19.6 - 16.8 17.4 19.1 - 16.4 17.0 18.6 - 15.6 16.2 17.7 - 14.4 15.0 16.4 -
S/T 0.72 0.60 0.42 - 0.75 0.63 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.69 0.48 - 0.83 0.69 0.48 -
Delta T 17 15 11 - 18 15 12 - 18 15 12 - 18 15 12 - 17 15 11 - 16 14 11 -
675 KW 1.26 1.29 1.33 - 1.36 1.38 1.43 - 1.44 1.47 1.52 - 1.51 1.54 1.59 - 1.57 1.61 1.66 - 1.63 1.66 1.72 -
AMPS 4.6 4.7 4.9 - 5.0 5.1 5.3 - 5.4 5.6 5.8 - 5.8 6.0 6.2 - 6.2 6.3 6.6 - 6.6 6.7 7.0 -
HI PR 213 230 242 - 239 258 272 - 272 293 309 - 310 334 352 - 349 375 396 - 385 415 438 -
LO PR 105 112 122 - 111 118 129 - 115 123 134 - 121 129 141 - 127 135 147 - 131 140 152 -
MBh 17.1 17.7 19.4 - 16.7 17.3 19.0 - 16.3 16.9 18.5 - 15.9 16.5 18.1 - 15.1 15.7 17.2 - 14.0 14.5 15.9 -
S/T 0.69 0.58 0.40 - 0.71 0.60 0.41 - 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.79 0.66 0.46 -
Delta T 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -
70 600 KW 1.25 1.28 1.32 - 1.35 1.37 1.42 - 1.43 1.46 1.50 - 1.50 1.53 1.58 - 1.56 1.60 1.65 - 1.61 1.65 1.70 -
AMPS 4.6 4.7 4.9 - 5.0 5.1 5.3 - 5.4 5.5 5.7 - 5.8 5.9 6.1 - 6.1 6.3 6.5 - 6.5 6.7 6.9 -
HI PR 211 227 240 - 237 255 269 - 270 290 306 - 307 330 349 - 345 372 392 - 382 411 434 -
LO PR 104 111 121 - 110 117 127 - 114 121 132 - 120 127 139 - 126 134 146 - 130 138 151 -
MBh 15.8 16.4 17.9 - 15.4 16.0 17.5 - 15.1 15.6 17.1 - 14.7 15.2 16.7 - 14.0 14.5 15.9 - 12.9 13.4 14.7 -
S/T 0.66 0.55 0.38 - 0.69 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.76 0.64 0.44 -
Delta T 18 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -
525 KW 1.22 1.25 1.29 - 1.31 1.34 1.38 - 1.39 1.42 1.47 - 1.46 1.49 1.54 - 1.52 1.56 1.61 - 1.57 1.61 1.66 -
AMPS 4.5 4.6 4.7 - 4.8 4.9 5.1 - 5.2 5.4 5.6 - 5.6 5.7 5.9 - 6.0 6.1 6.3 - 6.3 6.5 6.7 -
HI PR 205 220 233 - 230 247 261 - 261 281 297 - 298 320 338 - 335 361 381 - 370 398 421 -
LO PR 101 107 117 - 106 113 124 - 111 118 129 - 116 124 135 - 122 130 141 - 126 134 146 -
MBh 17.9 18.5 20.0 21.5 17.5 18.0 19.5 21.0 17.1 17.6 19.1 20.5 16.7 17.2 18.6 20.0 15.9 16.3 17.7 19.0 14.7 15.1 16.4 17.6
S/T 0.820.730.560.360.850.760.580.370.870.780.590.380.90 0.81 0.61 0.39 0.93 0.84 0.63 0.41 0.94 0.84 0.64 0.41
Delta T20181510201915112019151120 19 15 11 20 19 15 11 19 17 14 10
675 KW 1.27 1.30 1.34 1.38 1.37 1.40 1.44 1.48 1.45 1.48 1.53 1.58 1.52
1.56
1.61 1.66 1.59 1.62 1.67 1.73 1.64 1.68 1.73 1.79
AMPS 4.7 4.8 4.9 5.1 5.1 5.2 5.3 5.5 5.5 5.6 5.8 6.0 5.9
6.0
6.2 6.5 6.3 6.4 6.6 6.9 6.6 6.8 7.0 7.3
HI PR 216 232 245 255 242 260 275 287 275 296 313 326 313 337 356 371 352 379 400 418 389 419 442 461
LO PR 106 113 123 131 112 119 130 139 116 124 135 144 122 130 142 151 128 136 149 158 133 141 154 164
MBh 17.4 17.9 19.4 20.8 17.0 17.5 19.0 20.3 16.6 17.1 18.5 19.9 16.2 16.7 18.1 19.4 15.4 15.8 17.2 18.4 14.3 14.7 15.9 17.1
S/T 0.780.700.530.340.810.730.550.350.830.740.560.360.86 0.77 0.58 0.37 0.89 0.80 0.60 0.39 0.90 0.80 0.61 0.39
Delta T21191611211916112119161121 20 16 11 21 19 16 11 20 18 15 10
75 600 KW 1.26 1.29 1.33 1.37 1.36 1.38 1.43 1.47 1.44 1.47 1.52 1.56 1.51 1.54 1.59 1.65 1.57 1.61 1.66 1.71 1.63 1.66 1.72 1.77
AMPS 4.6 4.7 4.9 5.1 5.0 5.1 5.3 5.5 5.4 5.6 5.8 6.0 5.8 6.0 6.2 6.4 6.2 6.3 6.6 6.8 6.6 6.7 7.0 7.2
HI PR 213 230 242 253 239 258 272 284 272 293 309 323 310 334 352 368 349 375 396 414 386 415 438 457
LO PR 105 112 122 130 111 118 129 137 115 123 134 143 121
129
141 150 127 135 147 157 131 140 152 162
MBh 16.1 16.5 17.9 19.2 15.7 16.2 17.5 18.8 15.3 15.8 17.1 18.3 15.0 15.4 16.7 17.9 14.2 14.6 15.8 17.0 13.2 13.5 14.7 15.7
S/T 0.750.680.510.330.780.700.530.340.800.720.540.350.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.87 0.78 0.59 0.38
Delta T21201611222016112220161122
20
16 11 21 20 16 11 20 18 15 10
525 KW 1.23 1.26 1.30 1.34 1.32 1.35 1.39 1.44 1.41 1.43 1.48 1.53 1.48
1.51
1.55 1.61 1.54 1.57 1.62 1.67 1.59 1.62 1.67 1.73
AMPS 4.5 4.6 4.8 4.9 4.9 5.0 5.2 5.3 5.3 5.4 5.6 5.8 5.7 5.8 6.0 6.2 6.0 6.2 6.4 6.6 6.4 6.5 6.8 7.0
HI PR 207 223 235 245 232 250 264 275 264 284 300 313 301 324 342 357 338 364 385 401 374 402 425 443
LO PR 102 108 118 126 108 114 125 133 112 119 130 138 117 125 136 145 123 131 143 152 127 135 148 157
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ACCA (TVA) conditions
