46
Key
No.
Description Part No. Quantity
12. Transformer/Relay Assembly (Intermittent Circulation Only)
12A Junction Box, 4" x 4" x 1-1/2" 8136259 1
12B Transformer/Relay, Honeywell R8285D5001 80160155U 1
12C Relay, Honeywell R8222U1006 80160096U 1
12. Transformer (Continuous and Gravity Circulation Only)
12A Junction Box, 4" x 4" x 1-1/2" 8136259 1
12D Transformer, 40VA, Honeywell AT140D1012 or AT72D1188 80160039 1
13. Flame Rollout Switch
13A Flame Rollout Switch 80160044 1
13B Flame Rollout Switch Mounting Bracket 7186018 1
14. Blocked Vent Switch
14 Blocked Vent Switch Replacement Assembly 6016058 1
15. Ignition Module (EI Only)
15A Ignition Module, Honeywell S8610M3009 100958-01 1
15B Ignition Module Support Bracket 7016001 1
