16 en | Specifications Remote Command Center
F.01U.078.098 | 3.0 | 2011.11 Installation and Operation Guide Bosch Security Systems, Inc.
11.1.1 Wiring Specification
11.2 Mechanics
11.3 Environmental Conditions
11.4 Trademarks
Phillips is a registered trademark of the Phillips Screw Co.
Current consumption at 24 V DC/FWR
– Standby current 30 mA maximum (only Power LED on)
– Alarm current 120 mA maximum (with annunciator lit and piezo
on)
Cable entries 3 knockouts for 1/2 in. diameter conduit
connectors in the back, bottom and top side
Connections 2 connectors (4 terminals)
Wire gauge
AWG 12 to 18 (diameter 3.25 mm
2
to 0.75 mm
2
)
Wire type Non-shielded, four conductor wire
Maximum number of annunciators per
system
8 (FMR-1000-RA and/or FMR-1000-RCMD)
Distance allowed between FACP and
annunciator
2000 ft (610 m)
Maximum length of Option Bus wiring 4000 ft (1219 m), depending on cable gauge and
connected devices
Operating and display elements
– 6 LEDs Fire (red), Gas Alarm (blue), Power (green),
Supervisory, Silenced and Trouble (3 x yellow)
– LCD 4 line x 20 character LCD display, backlit
– Keys Keys for Drill, Reset, Silenced, Acknowledge [ACK],
4 arrow keys
– Piezo Built-in piezo sounder
Mounting holes back box 2, spaced 5.5 in. (140 mm) apart
Housing material ABS-FR
Color Red
Dimensions (W x H x D)
– FMR-1000-RCMD 7.40 x 4.41 x 2.40 in. (188 x 112 x 61 mm)
– Back box 7.40 x 4.41 x 1.89 in. (188 x 112 x 48 mm)
Weight 19.4 oz (550 g)
Environment Indoor, dry
Operating temperature 32 °F to 120 °F (0 °C to +49 °C)
Storage temperature -4 °F to 140 °F (-20 °C to +60 °C)
Relative humidity Up to 95%, non-condensing
Protection class per IEC 605029 IP 30
