701379-UIM-C-0712
34 Johnson Controls Unitary Products
Table 18: Air Flow Data
HIGH / LOW SPEED COOLING AND HEAT PUMP CFM
040A10 060B12 080B12 Jumper Settings
High Low High Low High Low COOL Tap ADJ Tap*
1080 750 1343 865 1320 882 A B
960 680 1116 727 1093 755 B B
980 690 1235 791 1203 810 A A
870 620 1026 661 1001 693 B A
890 620 1079 709 1080 730 A C
770 550 889 590 880 641 C B
790 560 900 599 910 642 B C
650 480 787 531 803 585 D B
700 500 814 542 836 597 C A
590 440 712 490 738 557 D A
640 450 725 499 749 561 C C
540 400 641 456 682 529 D C
080C16 100C16 100C20 Jumper Settings
High Low High Low High Low COOL Tap ADJ Tap*
1787 1171 1818 1192 2019 1290 A B
1503 987 1545 1030 1790 1174 B B
1620 1053 1661 1083 1818 1195 A A
1405 914 1427 936 1630 1068 B A
1462 964 1497 991 1649 1082 A C
1217 785 1234 819 1269 848 C B
1245 818 1265 832 1432 956 B C
940 608 977 648 1078 704 D B
1091 702 1116 728 1169 770 C A
852 551 884 572 986 638 D A
983 626 1019 666 1062 685 C C
764 544 791 519 866 576 D C
120D20 Jumper Settings
High Low COOL Tap ADJ Tap*
2006 1397 A B
1687 1131 B B
1845 1282 A A
1552 1050 B A
1694 1157 A C
1502 1011 C B
1400 944 B C
1365 922 D B
1364 931 C A
1232 808 D A
1225 808 C C
1117 718 D C
HIGH / LOW HEAT CFM
040A10 060B12 80B12 Jumper Settings
High Low High Low High Low HEAT Tap ADJ Tap*
960 670 1364 843 1433 945 A Any
840 590 1253 745 1320 887 B Any
740 520 1102 660 1223 840 C Any
640 450 1014 607 1134 768 D Any
80C16 100C16 100C20 Jumper Settings
High Low High Low High Low HEAT Tap ADJ Tap*
1684 1095 1803 1182 2194 1417 A Any
1542 1011 1686 1084 1999 1290 B Any
1426 927 1530 1016 1799 1182 C Any
1289 832 1427 936 1614 1062 D Any
120D20 Jumper Settings
High Low HEAT Tap ADJ Tap*
1937 1323 A Any
1757 1199 B Any
1594 1062 C Any
1429 957 D Any
All CFM’s are shown at 0.5” w.c. external static pressure.These units have variable speed motors that automatically adjust to provide constant CFM from 0.0” to 0.6”
w.c. static pressure. From 0.6” to 1.0” static pressure, CFM is reduced by 2% per 0.1” increase in static. Operation on duct systems with greater than 1.0” w.c. external
static pressure is not recommended.
NOTE: At some settings, LOW COOL and/or LOW HEAT airflow may be lower that what is required to operate an airflow switch on certain models of electronic air
cleaners. Consult the instructions for the electronic air cleaner for further details.
* The ADJ “D” tap should not be used.
