Janome MS-5027 Sewing Machine User Manual



36
1
1
1
Stitch Length Control
(how to adjust the stitch length)
Slide the stitch length control to the desired stitch length
number.
Set the stitch length control at S.S. when using a stretch
stitch. The higher the number, the greater the stitch length.
The mark shows the adjustment range when sewing the
buttonhole.
* Raise the presser foot before sliding the stitch length
control.
Stitch length control
Stitch Width Control
(how to adjust the stitch width)
Slide the stitch width control to the desired stitch width
number.
The higher the number, the greater the stitch width. The
mark shows the adjustment range when using the twin
needle. The blue zone is the appropriate adjustment range
for buttonhole sewing.
* Before sliding the stitch width control, be sure to raise the
needle above the fabric.
Stitch width control
1
