Operating Instructions
BURNER LIGHTING:
A) Make sure the pilot is lit.
B) Turn gas control knob COUNTER CLOCKWISE to ON.
C) Flip the burner switch to ON.
D) Turn HI/LO knob to the desired ame height.
E) Turn on all electrical power to the unit.
NOTE: Check that all burner holes are lit.
TO TURN GAS FIREPLACE OFF
Flip switch to OFF to turn off burners only.
If the replace is to be turned off for the season, or for
servicing, turn the gas shut off valve to OFF. DO NOT
FORCE IT. If the unit is going to be serviced, turn off the electrical power to the unit as well.
NOTE: When the unit is turned on for the rst time, it should be turned onto high, with the fan OFF, for
the rst four (4) hours. This will cure the paint, logs, gasket material, and other products used in the
manufacturing process. It is advised that a door or window be opened as the unit will start to smoke,
which can irritate some people. After the unit has gone through the rst burn, turn the unit OFF, including
the pilot, and let the unit get completely cold. Then remove the glass and clean it with a good gas
replace glass cleaner, available at your local Enviro dealer. See MAINTENANCE AND SERVICE - CLEANING THE
GLASS and MAINTENANCE AND SERVICE - GLASS DOOR REMOVAL.
REMOTE CONTROLS:
This replace can use an optional remote control or an optional cordless wall thermostat. If either of
these are to be used to control the replace for the majority of the time, leave the ON/OFF switch (on the
control panel) in the remote/thermostat position. Consult the instructions included with the remote/wall
thermostat for operation guidelines.
AIR DIVERTER CONTROL:
When the blower is on, the amount of air ow into the room can be adjusted
with the air diverter. When the lever is to the far left the room receives the
air, when the lever is to the far right the air goes out the duct and when
the lever in the middle the air goes to both the duct and the room. Lever is
found above the right end of the control panel, see Figure 6.
BLOWER SPEED:
The blower will come on only when the replace is up to temperature (approximately
20 minutes). The speed of the fan can be changed by turning the fan control knob.
To turn the blower off, turn the knob COUNTER CLOCKWISE until it “clicks” off
(Figure 7).
It is advisable not to operate the blower below
1
/3 speed as it puts a strain on the
windings of the blower and running the blower at lower speeds could also cause
premature fan failure.
Figure 5. Control Panel
Figure 7. Fan
Control
R
o
o
m
D
u
c
t
A
i
r
D
i
v
e
r
t
e
r
Figure 6. Air Diverter
8
