Physical data and electrical characteristics
Heat pump units
YLCC-H YLCC-H YLCC-H YLCC-H YLCC-H YLCC-H
42/42V 62/62V 82/82V 102/102V 122/122V 152/152V
Cooling capacity kW 42.2 59.5 72.5 94.9 116 145
Heating capacity kW 45.2 64.2 82.7 95.4 120 145
Amount 2 2 2 2 2 2
Type Scroll Scroll Scroll Scroll Tandem scroll Tandem scroll
Nominal power (cooling) (a) kW 8.2 (x2) 12.3 (x2) 13.9 (x2) 19.5 (x2) 24 (x2) 29,7 (x2)
Nominal power (heating) (a) kW 8.7 (x2) 12.6 (x2) 14.3 (x2) 19.9 (x2) 25,3 (x2) 28,4 (x2)
Power supply V.ph.Hz 400.3.50
Comp. consump. in cooling A 15.9 (x2) 22 (x2) 26.5 (x2) 34.4 (x2) 41,5 (x2) 54 (x2)
Comp. consump. in heating A 16.7 (x2) 22.8 (x2) 27.1 (x2) 35 (x2) 43,5 (x2) 52,2 (x2)
Starting current A 130 135 175 215 135 175
Oil charge l 3.25 3.3 6.6 8 6.6 6.6
Oil type Polyolester ISO32
Amount 2 2 2 2 2 2
Total nom. air flow m
3
/h 13 268 20 122 23 304 28 834 37 403 37 403
Fan size mm 12-12 15-15 15-15 18-18 18-18 18-18
Power (a) W 1 420 (x2) 2 507 (x2) 2 824 (x2) 3 988 (x2) 5 505 (x2) 5 856 (x2)
Fan consumption A 3.1 (x2) 4.9 (x2) 6.6 (x2) 7.4 (x2) 10,4 (x2) 10,8 (x2)
Starting current A 17 35 60 60 75 75
Power supply V.ph.Hz 400.3.50
Motor r.p.m. 1 420 1 430 1 420 1 420 1 425 1 425
Available pressure (b) Pa 50 50 50 50 50 50
Amount 2 2 2 2 2 2
Pipes depth x height 4 x 42 5 x 42 4 x 48 4 x 48 5 x 48 5 x 48
Fins per inch 14 14 16 16 16 16
Front surface m
2
1.02 (x2) 1.02 (x2) 1.56 (x2) 1.56 (x2) 1.77 (x2) 1.77 (x2)
Piper diameter 3/8"
Type Coaxial
bar 10 10 10 10 10 10
Nominal cold/hot water flow l/h 7107 / 6829 10041 / 10045 12211 / 13629 16165 / 16103 17 977/18 889 22 085/20 801
Water connections female G. 2" 2" 2
1
/
2
"2
1
/
2
"3" 3"
Water filter 2" 2" 2
1
/
2
"2
1
/
2
"3" 3"
Refrigerant charge R-407C kg 7.5 (x2) 8.6 (x2) 12.1 (x2) 12.1 (x2) 14,5 (x2) 20 (x2)
Sound power level dB(A) 79 81 82 84 86 90
Sound power level at 5 m dB(A) 57 59 60 62 64 70
Sound power level at 10 m dB(A) 51 53 54 56 58 62
Height mm 1 770 1 770 1 994 1 994 1 994 1 994
Width mm 2 340 2 340 2 991 2 991 3 300 3 300
Depth mm 883 1 029 1 150 1 150 1 400 1 400
IP 44 44 44 44 44 44
Nett kg 715 857 987 1 146 1 514 1 568
Gross kg 732 875 1 006 1 166 1 536 1 590
Compressor
Model
Centrifugal
fan
Outdoor
coil
Indoor
exchanger
Max. operating pressure
on water side
Dimensions
with packing
Approximate
weight
a) Consumption under nominal conditions.
b) Pressure under nominal conditions. See page 10 for other air flows.
