34
YLCC-H YLCC
F1 (FACTORY) Fan presence (0 = no, 1 = yes) 1 0
F3 (FACTORY) Minimum voltage threshold at triac (a) steps 0 0
F4 (FACTORY) Maximum voltage threshold at triac (b) steps 166 166
F5 (USER) Cooling cycle minimum speed temp. °C 35 35
F6 (USER) Cooling cycle minimum speed temp. °C 45 45
F7 (USER) Heating cycle minimum speed temp. °C 35 35
F8 (USER) Heating cycle maximum speed temp. °C 30 30
F9 (USER) Cooling cycle fan off temperature °C 20 20
FA (USER) Heating cycle fan off temperature °C 40 40
Fb (USER) Fan start time 4 secs. 0 0
F2 (USER) Operating mode. (0 = always ON; 1 = parallel with
comp.; 2 = parallel with comp. Reg. ON/OFF; 3 = parallel
with comp. Speed control).
Factory value
Unit
Parameter Description
11
- In “pump absent” mode, the flow switch alarm is deacti-
vated.
- The water pump will start 20 seconds before compressor
(c7) starts.
- When the compressor turns off, the pump will continue op-
erating for 20 minutes more (c8).
- To see pump operating hours, see DIRECT cC parameter.
Single-phase axial or centrifugal fans operation
with speed control
Speed selection is carried out in both the cooling as well as
the heating cycles.
Cooling cycle (compressor on)
Heating cycle (compressor on)
Cooling cycle cut-off
(F9)
Condensing temperature
Fan off
Minimum speed
Maximum speed
Cooling cycle minimum
speed temperature (F5)
Cooling cycle maximum
speed temperature (F6)
Heating cycle cut-off
(FA)
Evaporating
temperature
Fan off
Minimum speed
Maximum speed
Heating cycle minimum
speed temperature (F7)
Heating cycle maximum
speed temperature (F8)
