MUA-PRC001-EN28
Dimension and
Weights
Table DW-10
Model A B C D E F G H J K L M N P R
215 1' 4" 1' 6-
15/16
"7-
7/8
" 1' 0-
3/8
" 3' 0" 3' 0" 6' 5" 11' 3" 0' 3" 1' 10" 7' 10" 1' 2-¼" 1' 7" 5' 5-¾" 1' 10-¼"
(406) (481) (200) (314) (914) (914) (1956) (3429) (76) (559) (2388) (362) (483) (1670) (565)
218 1' 7" 1' 10-
1/16
"7-
7/8
" 1'
3/8
" 3' 0" 3' 0" 6' 5" 11' 3" 0' 3" 1' 10" 7' 10" 1' 2-¼" 1' 7" 5' 5-¾" 1' 4"
(483) (560) (200) (314) (914) (914) (1956) (3429) (76) (559) (2388) (362) (483) (1670) (406)
220 2' 0-
7/8
" 2' 1-
1/16
" 1' 0-
3/8
" 1' 1-
3/16
" 4' 0" 4' 0" 8' 0" 13' 10" 0' 4" 1' 10" 10' 10" 1' 2-¼" 1' 7" 7' 3-
3/8
" 2' 5-
5/8
"
(632) (637) (314) (335) (1219) (1219) (2438) (4216) (102) (559) (3302) (362) (483) (2219) (752)
222 2' 3-
3/8
" 2' 3-
9/16
" 1' 0-
3/8
" 1' 1-
3/16
" 4' 0" 4' 0" 8' 0" 13' 10" 0' 4" 1' 10" 10' 10" 1' 2-¼" 1' 7" 7' 3-
3/8
" 2' 5-
5/8
"
(695) (700) (314) (335) (1219) (1219) (2438) (4216) (102) (559) (3302) (362) (483) (2219) (752)
225 2' 7-
3/8
" 2' 7-½" 1' 3-
3/8
" 1' 5-
9/16
" 5' 0" 4' 0" 8' 0" 14' 4" 0' 4" 2' 4" 12' 10" 1' 8-¼" 1' 0-
5/16
" 9' 3-
3/8
" 3' 1-
5/8
"
(797) (800) (391) (446) (1524) (1219) (2438) (4369) (102) (711) (3912) (514) (313) (2829) (956)
230 3' 0-
7/8
" 3' 1" 1' 3-
3/8
" 1' 5-
9/16
" 5' 0" 4' 0" 8' 0" 14' 4" 0' 4" 2' 4" 12' 10" 1' 8-¼" 1' 0-
5/16
" 9' 3-
3/8
" 2' 2-
5/8
"
(937) (940) (391) (446) (1524) (1219) (2438) (4369) (102) (711) (3912) (514) (313) (2829) (676)
Notes:
1. Supply duct connection (by others) to be “pants-legged” from unit discharge.
2. Factory furnished support stand shipped separately for field mounting by others.
3. V-bank and inlet damper shown are optional components.
4. If V-bank section is ordered, it will ship mounted to the support stand.
5. If inlet damper is ordered, it will ship mounted in the support stand.
6. Refer to page 35 for unit weights.
Vertical Arrangement — Double Blower
Return Air Downstream of Burner—Arrangement 4
