Smith Cast Iron Boilers GB200 SERIES Boiler User Manual



Standing Pilot
5 Pilot Ass'y NG- Q314ALB, Q309A 72364 1 1 1
Pilot Ass'y NG- Q314ALB, Q309A 72365 1
Pilot Ass'y LP- Q314ALB, Q309A 72370 1111
Pilot Ass'y LP- Q314ALB, Q309D 72371 1
Thermocouple K16RA-30D 59109 1 1 1
Thermocouple K16RA-36D 51006 1
9 Gas Valve - NG VR8200H-1129 NG/LP* 59129 1111
28 Transformer 115/24 V, 43VA 50172 1111
Honeywell Intermittent Pilot System
5 Pilot Ass'y NG- Q3451B 72352 1 1 1
Pilot Ass'y NG- Q3451B 72353 1
Pilot Ass'y LP- Q3451B 72358 1 1 1
Pilot Ass'y LP- Q3451B 72359 1
Ignition Cable - 24" Lg. 59306 1 1 1
Ignition Cable - 30" Lg. 59307 1
9 Gas Valve - 24V NG VR8204H-1006 NG/LP* 59127 1111
28 Transformer 120/24 V, 43VA 50172 1111
30 Ignitor Control S8600M-1013 N.G./L.P. 51177 1111
17
REF
NO. NAME OF PART PART NO. GB200-3 GB200-4L GB200-4H GB200-5
*For L.P., also order Conversion Kit #50701.
