DIFFERENCE and COMPATIBILITY
of L300P series and SJ700B series
MEMO
Items
Retry or trip parameter
d001:Output frequency monitoring
d007:Scaled output frequency monitoring
Removable
Position
Others
110L
Installation
External radiating fin
Option position
SJ-DG
SJ-DN / SJ-DN2
SJ-LW
SJ-PBT
Screw diameter
150L/H
370L
550L
450H
L300P series SJ700B series
You can copy the parameter settings from the L300P series into the SJ700B series.
(You cannot copy the parameter settings from the SJ700B series to the L300P series because the SJ700B
series has many new functions and additional parameters.)
No display mode selection.
(full display)
Basic display mode/Data comparison function addition.
Note:basic display mode [factory setting])To display all
parameters,
specify "00" for "b037".
Instantaneous power failure/under-voltage/
overvoltage/overcurrent:It sets up by b001.
Instantaneous power failure/under-voltage:It sets
up by b001.
overvoltage/overcurrent:It sets up by b008.
300L/H:97mm upper part from L300P.
Other model:same position.
Those with compatibility.
Those with compatibility.
Note:Since the SJ700B series has many new functions and additional parameters,some functions of the
SJ-DN, SJ-LW, and SJ-PBT(option boards conforming to the open network specifications)cannot be
implemented on the SJ700B series. SJ-DN2 has compatibility to SJ700.
110,150LF/HF:10mm upper part from L300P.
185 to 370L/H:20mm upper part from L300P.
750L:30mm upper part from L300P.
Other model:same position.
Removable
185 to 300L/H:RB there is not a terminal.
All the models are possible.
Up to 15kW
All models are the same enclosure size.
Those with compatibility. Note 2
370L/H:97mm upper part from L300P.
Other model:same position.
17
185 to 300H:RB there is a terminal.
18.5kW or more is possible.
Up to 30kW
10
Removable
(You can mount the L300P into the SJ700B .)
You can not change the output frequency setting
by using the up and or down key.
You can not change the output frequency setting
by using the up and or down key.
A001:
Frequency source setting
Default:00
(Keypad potentiometer on digital operator)
Default:02
(Digital operator)
A016:
External frequency filter time const.
Default:8 Default:31 Note 1
A038:Jog frequency setting
Setting range:0 to 999Hz
Setting range:
0.01 to 999Hz(0Hz setup is impossible)
b095:Dynamic braking control
Default:00 (disabling)
Default:01 (enabling [disabling while the motor is
topped])
A105:
[OI]-[L] input start frequency enable
Default:01(external start frequency) Default:00(0Hz)
b012, b212, b312:
Electronic thermal function
Setting upper limit:120% Setting upper limit:100%
b013, b213, b313:
Electronic thermal characteristic
Default:00 (reduced-torque characteristic) Default:01 (constant-torque characteristic)
b092:Cooling fan control
Default:00 (always operating the fan)
Default:01 (operating the fan only during inverter
operation
[including 5 minutes after power-on and power-off])
Intelligent input terminals
5 terminals
8 terminals
Intelligent output terminals
2 terminals(Relay) 5 terminals(Open collector)
Position
370L/H:97mm upper part from L300P.
Other model:same position.
M6(Ground Screw) M5(Ground Screw)
M8(Ground Screw) M6(Ground Screw)
M10 M8
M6 M8
Copying the parameter settings
Parameter display mode.
Change function
Terminal
Minimum value of
resistor(Ω)
Easy-removable Dc bus Capacitor
150L
17 10
110H
50 35
150H
50 35
Yes. No.(Option)
Dynamic Brake circuit
Dimensions
Digital operator position
Keypad potentiometer on digital operator
Option boards
Control
circuit
Main
circuit
Note1:Since a response falls the V/F characteristic curve selection SLV should make this setup small.
Note2:450, 550L/H and 750H:Metal fittings differ.
