AN-2030: Digital Diagnostic Monitoring Interface for Optical Transceivers F i n i s a r
9/26/02 Revision D Page 14
Table 3.8: Diagnostic Monitoring Type 1
Data Address Bits Description
92 7
Reserved for legacy diagnostic
implementations. Must be ‘0’ for compilance
with this document.
92 6
Digital diagnostic monitoring implemented
(described in this document). Must be ‘1’ for
compliance with this document.
92 5 Internally Calibrated
92 4 Externally Calibrated
92 3
Received power measurement type
0 = OMA, 1 = Average Power
92 2
Address change required see section above,
“addressing modes”
92 1-0 Reserved
