© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
F232085
20
Mounting Bolt Hole Locations
PHM635N
Figure 3
30-1/2 in.
(774 mm)
29 in.
(737 mm)
22-3/4 in.
(578 mm)
28-5/8 in.
(727 mm)
39-1/32 in.
(991 mm)
35-1/8 in.
(892 mm)
30-1/8 in.
(765 mm)
26-1/8 in.
(664 mm)
2 in.
(51 mm)
2 in.
(51 mm)
UW35
FRONT
OUTLINE OF
FRAM BASE
FRONT OF MACHINE
3/4 in.
(19 mm)
