Installation
15
F232085
UW 2 Speed Pocket Hardmount Models
Specifications UW35 UW60
Drive Train Information
Number of motors in drive train 1 1
Wash/reverse motor power, hp (kW) 0.4 (0.3) 0.6 (0.5)
High extract motor power, hp (kW) 1.8 (1.3) 3.0 (2.2)
Cylinder Speeds / Centrifugal Force Data
Wash/reverse speed, rpm/g 50 / 0.95 44 / 0.88
Distribution speed, rpm/g – –
High extract speed, rpm/g 504 / 95 465 / 98
Balance Detection
Vibration safety switch installed N/A STD
Safety switch gap setting, in. (mm) N/A 0.008-0.010
(0.20-0.25)
Direct Steam Heating (Optional)
Steam inlet connection size, in. (mm) 1/2 (13) 1/2 (13)
Number of steam inlets 1 1
Steam required to raise bath temperature 10°F, lb (10°C, kg) LOW 2.1 (1.5) 3.3 (2.4)
MED 2.3 (1.7) 3.7 (2.6)
HIGH 2.7 (1.9) 4.1 (2.9)
Average consumption per cycle, BHP (kg/hr) 1.4 (21.4) 2.1 (33.4)
Electrical Heating (Optional)
Total electrical heating capacity, kW 15.6 25.2
Number of electrical heating elements 6 6
Electrical heating element size, kW 2.6 4.2
Time required to raise bath temperature 10°F, min (10°C, min) LOW 2.4 (3.6) 2.4 (3.7)
MED 2.7 (4.1) 2.7 (4.1)
HIGH 3.1 (4.7) 3.0 (4.6)
* For P and S control only. M and B control have no spray rinse.
Table 1 (Continued)
