1 - 28
1. FUNCTIONS AND CONFIGURATION
(6) MR-J3-700A(4)
R S T
L
21
P2
P
1
CN5
CN3
CN2
CN4
CN1
CN6
L
11
UVW
CP
L1
L
2
L3
Line noise filter
(FR-BLF)
(Note 3)
Power supply
Magnetic
contactor
(MC)
No-fuse breaker
(NFB) or fuse
(Note 2)
(Note 2)
Power factor
improving DC
reactor
(FR-BEL-(H))
Servo amplifier
Regenerative
option
(Note 1)
Battery
MR-J3BAT
Servo motor
Junction terminal block
MR Configurator
Personal
computer
Analog monitor
Note 1. The battery (option) is used for the absolute position detection system in the position control mode.
2. The power factor improving AC reactor can also be used. In this case, the power factor improving DC reactor cannot be used.
When not using the power factor improving DC reactor, short P
1 and P2.
3. Refer to section 1.3 for the power supply specification.
