12. OPTIONS AND AUXILIARY EQUIPMENT
(f) MR-RB1H-4
[Unit: mm]
6
2
149
173
6
Approx. 24
15
36
40
6 mounting hole
Terminal signal layout
G3
G4
P
C
Applicable wire size: 0.2 to 4.0mm
2
(AWG24 to AWG10)
Tightening torque: 0.5 to 0.6 [N
m]
(4.43 to 5.31 [lb
in])
Mounting screw
Screw size: M5
Tightening torque: 3.24 [N
m]
(28.32 [lb
in])
Mass: 1.1[kg] (2.4 [lb])
(g) MR-RB032
[Unit: mm]
T
E1
30
15
Approx. 20
99
1.6
119
6
5
6 mounting hole
TE1
Terminal block
G3
G4
P
C
Applicable wire size: 0.2 to 2.5mm
2
(AWG24 to AWG12)
Tightening torque: 0.5 to 0.6 [N
m]
(4 to 5 [lb
in])
Mounting screw
Screw size: M5
Tightening torque: 3.24 [N
m]
(28.7 [lb
in])
Mass: 0.5 [kg] (1.1 [lb])
