Enterasys Matrix DFE-Gold Series Configuration Guide 4-1

4

Port Configuration

ThischapterdescribesthePortConfigurationsetofcommandsandhowtousethem.

Port Configuration Summary

Console Port(s)

EachMatrixSeriesmoduleorstandalonedeviceincludesaconsoleportthroughwhichlocal

managementofthedevicecanbeaccessedusingaterminalormodem.

Fordetailsonconfiguringoneormoreconsoleportsettings,referto“SettingConsolePort

Properties”onpage 4‐3.

Formoduleplacementrulesand

considerationsforconfiguringlocalmanagementonDFE‐Gold

modules,refertotheMatrixDFE‐GoldSeriesInstallationGuide.

FordetailsonactivatingredundancyonaDFE‐GoldSeriesmodule,referto“ActivatingLicensed

Features”onpage 2 ‐58.

Important Notice

CLI examples in this guide illustrate a generic Matrix command prompt and chassis-based / modular port

designations. Depending on which Matrix Series device you are using, your default command prompt and

output may be different than the examples shown.

For information about... Refer to page...

Port Configuration Summary 4-1

Setting Console Port Properties 4-3

Reviewing Port Status 4-13

Disabling / Enabling and Naming Ports 4-20

Setting Speed and Duplex Mode 4-24

Enabling / Disabling Jumbo Frame Support 4-27

Setting Auto-Negotiation and Advertised Ability 4-30

Setting Flow Control 4-37

Configuring Link Traps and Link Flap Detection 4-39

Configuring Broadcast Suppression 4-49

Configuring Port Mirroring 4-52

Configuring LACP 4-55
