Reference, Installation, and Operations Manual Section 5: Startup and meter configuration
3-9000-743 Rev S June 2013
Meter configuration using Daniel MeterLink 131
Gas Chromatograph
Setup Page
• Serial Port
• GC protocol
– ASCII Modbus: 7 data bits, Even parity, and 1 stop bit
– RTU Modbus: 8data bits, No parity, and 1 stop bit
• GC baud rate
• GC comms address
• Modbus ID of the GC
• GC stream number
• GC heating value units
• GC heating value type
– BTU-Dry
– BTU-Saturated
– BTU-Actual
• Use which gas composition on GC alarm
– Last good value
– Fixed value
AGA8 Page AGA8 Calculations:
• Internally (by the meter)
Enter values for Base temperature and Base pressure
• Select Method to be used:
– Gross Method 1
– Gross Method 2
– Detail
• Use which gas composition:
– Fixed
– Live GC
• Base temperature
– Base pressure
• Volumetric gross heating value
– Volumetric gross heating value ref temperature
– Molar density ref temperature
– Molar density ref pressure
• Externally (by Daniel MeterLink or a flow computer or SCADA system)
– Flow mass density
– Flow compressibility
– Base compressibility
Continuous Flow Analysis
Page
• Flow Limits
• SOS comparison (requires AGA 8 Detail method to be used)
• Liquid detection
• Abnormal profile
• Blockage
• Internal bore buildup
Table 5-11 Daniel MeterLink Field Setup Wizard
Page Description
