AXIS 231D+/232D+ - Event Configuration
Event Configuration
This section describes how to configure the AXIS 231D+/232D+ for event handling. The
AXIS 231D+/232D+ can be configured to perform certain actions when certain types of
events occur.
Event Servers
Event Servers can be used for receiving uploaded image files and/or notification messages.
To set up Event server connections in your AXIS 231D+/232D+, go to Setup > Event
Configuration > Event Servers and enter the required information according to the
selected server type.
For details on each setting, refer to
the online help files available from each web page.
When the set up is complete, the connection can be tested by clicking the Test button
(the
connection test will take approximately 10 seconds).
Server type Purpose Requires information
FTP Server
•
used for uploading saved images • IP/Hostname
• Descriptive name of your choice
• User Name and Password (to FTP server)
HTTP Server • used for notification messages
•
used for uploading saved images
• Descriptive name of your choice
•URL
• User Name and Password (to HTTP server)
TCP Server • used for notification messages • IP/Hostname
•
Descriptive name of your choice
• Port number e.g. port 80
