AXIS 231D+/232D+ - Live View Config
For more information on the Axis HTTP API, see the Support / Developer pages on the
Axis Web site at http://www.axis.com.
Please use the online help files for more information.
For more information on the Axis HTTP API, see
the Support / Developer pages on the
Axis Web site at http://www.axis.com. See also the section on PTZ, on page 24.
Action Buttons
These buttons can be used to manually trigger and stop an event from the Live View page.
The snapshot button allows you to take a snapshot of the video stream and save it to a
computer.
Output Buttons
These buttons are used to control the outputs on the AXIS 231D+/232D+ and thus the
equipment connected to them, such as to switch a light on or off:
• The Pulse button activates the port for a defined period
• Active/Inactive displays two buttons, one for each action
(on/off)
Default Video Format
Select the default video format to use on the Live View page. Checking the box for Show
video format selection displays a drop-down list on the Live View page allowing you to
temporarily change the format.
When using MPEG-4 as the video format, the default
viewer is AXIS Media Control with
Internet Explorer.
Note:
It is also possible to view Motion JPEG when MPEG-4 is chosen as default and vice versa.
Default Viewer
From the drop-down lists, select the default method for viewing video images in your
browser. The camera attempts to show the video images in the selected video format and
viewer. If this is not possible, the camera overrides the settings and selects the best
available combination.
Browser Viewer Description
Windows
Internet Explorer
AMC Recommended viewer in Windows Internet Explorer (MPEG-4
/Motion JPEG).
QuickTime MPEG-4 only.
Java applet A slower imaging alternative to AMC. Requires one of
the following installed on the client:
• JVM (J2SE) 1.4.2 or higher
•
JRE (J2SE) 5.0 or higher
Still image Displays still images only. Hit the Refresh button in your browser to view a new image.
Other browsers
Server Push Recommended viewer for other browsers (Motion JPEG).
QuickTime MPEG-4 only.
Java applet A slower imaging alternative to Server
Push (Motion JPEG only).
Still image Displays still images only. Hit the Refresh button in your browser to view a new image.
