246645-YTG-C-0708
16 Johnson Controls Unitary Products
TABLE 8: COOLING CAPACITY DM120 (10 TON) UNIT
Air On
Evap. Coil
Temperature of Air on Condenser Coil 85°F Temperature of Air on Condenser Coil 95°F
CFM
WB
(°F)
Tot.
Cap.*
(MBH)
Tot.
Input
†
(kW)
Sensible Capacity (MBH)
*
Return Dry Bulb (°F)
Tot.
Cap.
*
(MBH)
Tot.
Input
†
(kW)
Sensible Capacity (MBH)
*
Return Dry Bulb (°F)
86 83 80 77 74 71 68 86 83 80 77 74 71 68
3000
72 132 11.0 76 68 59 50 42 - - 125 11.7 74 65 57 48 40 - -
67 124 10.7 96 87 79 70 62 53 45 116 11.4 93 84 75 67 58 50 41
62 116 10.5 115 106 98 89 81 72 64 106 11.1 106 100 91 82 74 65 57
57 110 10.3 110 109 101 92 83 75 66 106 11.1 106 103 95 86 78 69 61
3500
72 135 11.1 83 73 63 53 43 - - 129 11.8 82 72 62 52 41 - -
67 127 10.8 104 94 84 74 64 54 44 120 11.5 102 92 82 72 62 52 42
62 119 10.6 118 114 105 95 84 74 64 110 11.2 110 106 99 89 79 69 58
57 112 10.4 112 112 108 98 87 77 67 109 11.2 109 108 103 93 83 73 63
4000
72 138 11.2 91 79 67 56 44 - - 133 12.0 90 78 67 55 43 - -
67 130 10.9 113 101 90 78 66 55 43 124 11.7 112 100 89 77 65 54 42
62 121 10.7 121 121 111 100 88 76 65 113 11.3 113 113 107 95 84 72 60
57 115 10.5 115 115 115 103 91 80 68 113 11.3 113 113 111 100 88 76 65
4500
72 141 11.3 98 85 71 58 45 - - 135 12.0 96 83 70 56 43 - -
67 132 11.0 122 108 95 82 69 55 42 126 11.7 119 106 92 79 66 53 39
62 124 10.7 124 124 118 105 92 78 65 115 11.4 115 115 112 98 85 72 58
57 117 10.5 117 117 117 104 90 77 64 115 11.4 115 115 114 101 88 74 61
5000
72 144 11.3 105 90 75 60 45 - - 138 12.1 102 87 72 58 43 - -
67 135 11.0 130 116 101 86 71 56 41 128 11.8 126 111 96 81 67 52 37
62 126 10.8 126 126 125 110 95 80 65 117 11.5 117 117 116 101 86 71 57
57 119 10.6 119 119 119 105 90 75 60 117 11.5 117 117 117 102 87 72 57
Temperature of Air on Condenser Coil 105°F Temperature of Air on Condenser Coil 115°F
3000
72 117 12.4 70 62 53 45 36 - - 109 13.1 67 58 50 41 33 - -
67 107 12.0 89807163544637 97 12.5 85766759504233
62 97 11.6 97 94 85 77 68 60 51 88 12.2 88 88 80 71 62 54 45
57 98 11.7 98 96 88 79 71 62 54 91 12.3 91 89 81 72 64 55 46
3500
72 121 12.5 78 68 58 48 38 - - 113 13.2 75 64 54 44 34 - -
67 110 12.1 98 88 78 68 57 47 37 100 12.6 94 83 73 63 53 43 33
62 100 11.7 100 99 93 83 73 62 52 91 12.3 91 91 87 76 66 56 46
57 102 11.81021009585756555 94 12.4 94938878675747
4000
72 124 12.7 86 74 63 51 39 - - 116 13.4 82 70 59 47 35 - -
67 113 12.2 107 96 84 72 61 49 37 103 12.8 103 91 79 68 56 44 33
62 103 11.9 103 103 100 89 77 65 54 94 12.4 94 94 94 82 70 59 47
57 105 11.9 105 105 103 91 80 68 56 97 12.5 97 97 95 83 71 60 48
4500
72 127 12.8 93 79 66 53 39 - - 119 13.5 89 76 63 49 36 - -
67 116 12.31121028875624935 106 12.9106988471584531
62 106 12.0 106 106 104 91 77 64 51 96 12.5 96 96 96 83 70 56 43
57 107 12.0 107 107 106 93 80 66 53 99 12.6 99 99 98 85 72 59 45
5000
72 130 12.9 99 84 69 54 40 - - 123 13.6 96 81 66 51 37 - -
67 119 12.4 117 108 93 78 63 48 33 109 13.0 109 104 90 75 60 45 30
62 108 12.1 108 108 107 93 78 63 48 99 12.7 99 99 99 84 69 54 39
57 110 12.1 110 110 110 95 80 65 50 102 12.7 102 102 102 87 72 57 42
Temperature of Air on Condenser Coil 125°F
3000
72 101 13.8 6455463829 - -
67 87 13.0 80 72 63 55 46 38 29
62 79 12.7 79 79 74 65 57 48 40
57 83 12.9 83 82 74 65 56 48 39
3500
72 105 14.0 7161514030 - -
67 90 13.2 89 79 69 59 49 39 29
62 81 12.9 81 81 80 70 60 50 40
57 86 13.0 86 85 80 70 60 50 40
4000
72 108 14.1 7866554331 - -
67 92 13.3 92 86 75 63 51 40 28
62 84 13.0 84 84 84 75 64 52 40
57 88 13.1 88 88 87 75 63 52 40
4500
72 112 14.2 8672594632 - -
67 96 13.4 96 94 80 67 54 41 27
62 87 13.1 87 87 87 75 62 49 35
57 91 13.2 91 91 90 77 64 51 37
5000
72 115 14.4 9378634833 - -
67 99 13.6 99 99 86 71 56 41 27
62 89 13.3 89 89 89 75 60 45 30
57 94 13.4 94 94 94 79 65 50 35
* These capacities are gross ratings. For net
capacity, deduct air blower motor, MBH = 3.415
x kW. Refer to the appropriate Blower Perfor-
mance Table for the kW of the supply air
blower motor.
† These ratings include condenser fan motors
and the compressor motors but not the supply
air blower motor.
