246645-YTG-C-0708
Johnson Controls Unitary Products 15
TABLE 7: COOLING CAPACITY DM102 (8-1/2 TON) UNIT
Air on Evap-
orator Coil
Temperature of Air on Condenser Coil
75°F 85°F
CFM
WB
(°F)
Total
Cap.
*
(MBH)
Total
†
Input
(kW)
Sensible Capacity (MBH)
*
Return Dry Bulb (°F)
Total
Cap.
*
(MBH)
Total
†
Input
(kW)
Sensible Capacity (MBH)
*
Return Dry Bulb (°F)
86 83 80 77 74 71 68 86 83 80 77 74 71 68
2550
72 123.8 7.4 68.9 61.6 54.3 47.1 39.8 - - 114.8 8.0 65.3 58.0 50.8 43.5 36.2 - -
67 112.4 7.3 85.2 78.0 70.7 63.4 56.2 48.9 41.6 104.3 7.9 81.9 74.6 67.3 60.1 52.8 45.5 38.3
62 106.9 7.1 106.9 95.5 88.1 80.8 73.5 66.3 59.0 96.4 7.7 96.4 90.7 83.5 76.2 68.9 61.6 54.4
57 99.3 7.1 99.3 98.9 91.5 84.2 76.9 69.7 62.4 93.2 7.7 93.2 92.9 85.7 78.4 71.1 63.9 56.6
2975
72 127.6 7.4 75.6 67.0 58.5 49.9 41.3 - - 118.7 8.1 72.0 63.4 54.8 46.2 37.6 - -
67 115.9 7.3 93.2 84.6 76.0 67.4 58.8 50.2 41.7 107.8 7.9 89.9 81.3 72.7 64.1 55.5 46.9 38.3
62 110.3 7.2 110.3 104.6 94.7 86.1 77.5 69.0 60.4 99.7 7.7 99.7 96.9 90.1 81.5 72.9 64.3 55.7
57 102.4 7.1 102.4 102.2 98.4 89.8 81.2 72.6 64.0 96.3 7.8 96.3 96.2 92.5 83.9 75.3 66.7 58.1
3400
72 131.5 7.5 82.4 72.5 62.6 52.6 42.7 - - 122.6 8.2 78.7 68.7 58.8 48.9 39.0 - -
67 119.4 7.4 101.2 91.3 81.3 71.4 61.5 51.6 41.7 111.3 8.0 97.9 88.0 78.0 68.1 58.2 48.3 38.4
62 113.7 7.2 113.7 113.7 101.4 91.5 81.5 71.6 61.7 103.0 7.8 103.0 103.0 96.7 86.8 76.9 67.0 57.1
57 105.5 7.2 105.5 105.5 105.3 95.4 85.5 75.5 65.6 99.5 7.8 99.5 99.5 99.3 89.4 79.5 69.5 59.6
3825
72 134.7 7.5 88.7 77.5 66.2 54.9 43.6 - - 125.2 8.2 85.0 73.7 62.4 51.1 39.8 - -
67 122.3 7.4 110.0 97.3 86.0 74.7 63.4 52.1 40.9 113.7 8.0 105.4 94.1 82.8 71.5 60.2 48.9 37.6
62 116.4 7.3 116.4 116.4 110.3 99.0 87.7 76.4 65.1 105.2 7.8 105.2 105.2 102.1 90.8 79.5 68.2 56.9
57 108.1 7.3 108.1 108.1 108.0 96.7 85.4 74.1 62.8 101.6 7.9 101.6 101.6 101.5 90.2 78.9 67.6 56.4
4250
72 137.9 7.6 95.1 82.4 69.8 57.1 44.4 - - 127.8 8.3 91.3 78.7 66.0 53.3 40.7 - -
67 125.3 7.5 118.8 103.4 90.7 78.0 65.4 52.7 40.0 116.1 8.1 112.9 100.2 87.6 74.9 62.2 49.6 36.9
62 119.2 7.3 119.2 119.2 119.2 106.5 93.8 81.2 68.5 107.4 7.9 107.4 107.4 107.4 94.8 82.1 69.4 56.8
57 110.7 7.3 110.7 110.7 110.7 98.0 85.3 72.6 60.0 103.8 7.9 103.8 103.8 103.8 91.1 78.4 65.8 53.1
95°F 105°F
2550
72 105.8 8.7 61.7 54.5 47.2 39.9 32.6 - - 96.9 9.4 58.0 50.8 43.5 36.2 29.0 - -
67 96.1 8.5 78.5 71.3 64.0 56.7 49.5 42.2 34.9 86.6 9.1 74.3 67.0 59.7 52.5 45.2 37.9 30.7
62 86.0 8.3 86.0 86.0 78.8 71.6 64.3 57.0 49.7 79.4 8.9 79.4 78.9 71.7 64.4 57.1 49.9 42.6
57 87.0 8.3 87.0 87.0 79.9 72.6 65.3 58.1 50.8 79.5 8.9 79.5 79.4 72.2 65.0 57.7 50.4 43.2
2975
72 109.7 8.8 68.3 59.7 51.1 42.5 34.0 - - 100.5 9.4 64.6 56.0 47.4 38.8 30.2 - -
67 99.7 8.5 86.6 78.0 69.4 60.8 52.2 43.6 35.0 89.8 9.1 81.5 73.7 65.1 56.5 47.9 39.3 30.7
62 89.1 8.3 89.1 89.1 85.4 76.8 68.3 59.7 51.1 82.3 9.0 82.3 82.1 78.1 69.5 60.9 52.3 43.7
57 90.2 8.4 90.2 90.2 86.6 78.0 69.4 60.8 52.2 82.5 9.0 82.5 82.4 78.7 70.1 61.5 52.9 44.3
3400
72 113.6 8.8 74.9 65.0 55.1 45.2 35.3 - - 104.0 9.5 71.1 61.2 51.3 41.3 31.4 - -
67 103.2 8.6 94.6 84.7 74.7 64.8 54.9 45.0 35.1 93.0 9.2 88.7 80.3 70.4 60.5 50.6 40.7 30.8
62 92.3 8.4 92.3 92.3 92.1 82.1 72.2 62.3 52.4 85.3 9.0 85.3 85.3 84.5 74.6 64.6 54.7 44.8
57 93.5 8.4 93.5 93.5 93.3 83.4 73.5 63.5 53.6 85.4 9.1 85.4 85.4 85.1 75.2 65.3 55.4 45.5
3825
72 115.7 8.9 81.2 70.0 58.7 47.4 36.1 - - 105.6 9.5 77.4 66.1 54.8 43.5 32.2 - -
67 105.1 8.6 100.8 90.9 79.6 68.3 57.0 45.7 34.4 94.5 9.2 92.3 85.7 75.3 64.0 52.7 41.4 30.1
62 94.0 8.4 94.0 94.0 93.9 82.6 71.3 60.0 48.7 86.6 9.1 86.6 86.6 86.2 74.9 63.6 52.3 41.0
57 95.2 8.5 95.2 95.2 95.1 83.8 72.5 61.2 49.9 86.7 9.1 86.7 86.7 86.6 75.3 64.0 52.7 41.4
4250
72 117.7 8.9 87.6 74.9 62.2 49.6 36.9 - - 107.3 9.6 83.7 71.0 58.3 45.7 33.0 - -
67 107.0 8.7 107.0 97.1 84.4 71.8 59.1 46.4 33.7 95.9 9.3 95.9 91.0 80.2 67.5 54.8 42.1 29.5
62 95.7 8.5 95.7 95.7 95.7 83.0 70.4 57.7 45.0 87.9 9.1 87.9 87.9 87.9 75.3 62.6 49.9 37.3
57 96.9 8.5 96.9 96.9 96.9 84.2 71.5 58.9 46.2 88.1 9.1 88.1 88.1 88.1 75.4 62.7 50.1 37.4
115°F 125°F
2550
72 88.0 10.0 54.3 47.1 39.8 32.5 25.3 - - 79.1 10.7 50.7 43.4 36.1 28.8 21.6 - -
67 77.2 9.7 70.0 62.8 55.5 48.2 40.9 33.7 26.4 67.7 10.2 65.8 58.5 51.2 44.0 36.7 29.4 22.1
62 72.9 9.6 72.9 71.8 64.5 57.3 50.0 42.7 35.5 66.3 10.2 66.3 64.7 57.4 50.1 42.9 35.6 28.3
57 72.1 9.6 72.1 71.9 64.6 57.3 50.1 42.8 35.5 64.6 10.2 64.6 64.3 57.0 49.7 42.4 35.2 27.9
2975
72 91.2 10.1 60.8 52.2 43.6 35.0 26.4 - - 82.0 10.7 57.0 48.4 39.8 31.3 22.7 - -
67 80.0 9.7 76.4 69.4 60.8 52.2 43.6 35.0 26.4 70.2 10.3 70.2 65.1 56.5 47.9 39.3 30.7 22.1
62 75.5 9.6 75.5 75.0 70.7 62.1 53.5 44.9 36.3 68.7 10.2 68.7 68.0 63.4 54.8 46.2 37.6 29.0
57 74.7 9.6 74.7 74.6 70.8 62.2 53.6 45.0 36.4 67.0 10.2 67.0 66.8 62.9 54.3 45.7 37.1 28.5
3400
72 94.5 10.1 67.2 57.3 47.4 37.5 27.6 - - 84.9 10.8 63.4 53.5 43.6 33.7 23.7 - -
67 82.8 9.8 82.8 76.0 66.1 56.2 46.3 36.4 26.4 72.6 10.4 72.6 71.7 61.8 51.9 41.9 32.0 22.1
62 78.2 9.7 78.2 78.2 76.9 67.0 57.1 47.1 37.2 71.2 10.3 71.2 71.2 69.3 59.4 49.5 39.6 29.6
57 77.4 9.7 77.4 77.4 77.0 67.1 57.1 47.2 37.3 69.3 10.3 69.3 69.3 68.8 58.9 49.0 39.1 29.2
3825
72 95.6 10.2 73.5 62.2 50.9 39.6 28.3 - - 85.6 10.9 69.6 58.3 47.1 35.8 24.5 - -
67 83.9 9.8 83.9 80.4 71.0 59.7 48.4 37.1 25.8 73.2 10.4 73.2 73.2 66.7 55.4 44.1 32.8 21.5
62 79.2 9.7 79.2 79.2 78.5 67.2 55.9 44.6 33.4 71.8 10.4 71.8 71.8 70.8 59.6 48.3 37.0 25.7
57 78.3 9.7 78.3 78.3 78.1 66.8 55.5 44.3 33.0 69.9 10.4 69.9 69.9 69.7 58.4 47.1 35.8 24.5
4250
72 96.8 10.2 79.8 67.1 54.4 41.8 29.1 - - 86.3 10.9 75.9 63.2 50.5 37.9 25.2 - -
67 84.9 9.9 84.9 84.9 75.9 63.2 50.5 37.9 25.2 73.8 10.5 73.8 73.8 71.6 58.9 46.3 33.6 20.9
62 80.2 9.8 80.2 80.2 80.2 67.5 54.8 42.1 29.5 72.4 10.4 72.4 72.4 72.4 59.7 47.0 34.4 21.7
57 79.3 9.8 79.3 79.3 79.3 66.6 53.9 41.3 28.6 70.5 10.4 70.5 70.5 70.5 57.8 45.1 32.5 19.8
* The capacities are gross ratings. For net capacity, deduct indoor blower motor, MBH=3.415 x kW. Refer to the appropriate Blower Perfor-
mance table for the kW of the supply air blower motor.
† These ratings include the condenser fan motors (total 1 kW) and the compressor motors but not the supply air blower motor.
