246645-YTG-C-0708
Johnson Controls Unitary Products 11
TABLE 2: DM PHYSICAL DATA
Component
Models
078 090 102 120 150
Evaporator
Blower
Blower, Centrifugal (Dia. X Wd. in.) 15 x 15 12 x 12 12 X 12 15 x 15 15 x 15
Motor, Standard (HP)
1-1/2 2 3 2 3
Motor, Optional (HP)
2 3 3 3 5
Evaporator
Coil
Rows
2 2 3 2 3
Fins per Inch
15 15 15 15 15
Height (in.)
30 32 32 40 40
Face Area (ft.
2
each)
9.9 10.67 10.67 13.2 13.2
Condenser
Fan
(2 per Unit)
Propeller Dia. (in., each)
24 24 24 24 24
Motor (HP, each)
1/3 3/4 3/4 3/4 3/4
CFM, Nominal (each)
1700 2200 2200 2200 2200
Condenser
Coil
(2 per unit)
Rows (each)
1 1 1 1 2
Fins per Inch
20 20 20 20 20
Height (in. each)
24 28 36 44 44
Face Area (ft.
2
each)
7.9 9.33 12 14.5 14.5
Refrigerant
Charge
System 1 (lb./oz.)
4/6 4/10 5/8 6/12 10/12
System 2 (lb./oz.)
4/0 3/14 5/2 6/12 11/0
Compressors
Quantity
2 2 2 2 2
Type
Recip Recip Recip. Recip Scroll
Air Filters
Size (Wd. x Ht. x Thickness in.)
25x20x2 25x16x2 25x16x2 25x20x2 25x20x2
Number Per Unit
4 4 4 4 4
