035-12984-001-A-0204
Unitary Products Group 7
FIG. 5 - ENTHALPY SET POINT ADJUSTMENT
MODELS
BCH
048 060
SUPPLY AIR
BLOWER
CENTRIFUGAL BLOWER (Dia. x
Wd.,mm/in.)
FAN MOTOR HP (Direct-Drive Units)
FAN MOTOR HP (Belt-Drive Units)
305 x254
12 x 10
0.75
NA
305 x 254
12 x 10
NA
1.5
INDOOR
COIL
ROWS DEEP
FINS PER 25mm (1 inch)
FACE AREA (m
2
/ft
2
)
3
15
0.47 / 5.1
3
15
0.47 / 5.1
OUTDOOR
FAN
PROPELLER DIA. (mm/in.)
FAN MOTOR kW/HP
NOM. CFM TOTAL
610 / 24
0.37 / 0.5
4,200
610 / 24
0.37 / 0.5
4,500
OUTDOOR
COIL
ROWS DEEP
FINS PER 25mm (1 inch)
FACE AREA (m
2
/ft
2
)
1
20
17.1
1
20
17.1
AIR
FILTERS
(SEE NOTE)
QUANTITY PER UNIT (14" x 20" x 1")
QUANTITY PER UNIT (14" X 25" X 1")
TOTAL FACE AREA(m
2
/ ft
2
.)
2
1
6.3
2
1
6.3
CHARGE REFRIGERANT 22 (kg / lbs./oz.) 4.2 / 9.2 3.7 / 8/4
NOTE: Filter racks are adapted for 1" or 2" thick filters.
TABLE 3 - PHYSICAL DATA
WEIGHTS (kg/lbs)
Basic Unit
048 270 / 595
060 281 / 620
OPTIONS / ACCESSORIES
Electric Heat
(Nominal Kw)
5 - 7 kW 8.2 / 18
10 - 15 kW 10.4 / 23
20 - 30 kW 12.7 / 28
Economizer
22.7 / 50
Motorized Outdoor Air
Damper
21.8 / 48
Barometric Relief/Fixed
Outdoor Air Intake Damper
4.5 / 10
Roof Mounting Curb
41.7 / 92
Belt-Drive Blower
2.3 / 5
