GENERAL
YORK Model BCH units are single package heat pumps
designed for outdoor installation on a rooftop or a slab.
Supplemental electric heaters are available as field-installed
accessories. The units are manufactured under ISO 9002
Quality System Certification.
Units are completely assembled on rigid, permanently
attachedbaserails.All piping,refrigerantcharge, andelectrical
wiring is factory-installed and tested. The units require only
electricpowerandduct connectionsatthepoint ofinstallation.
The supplemental electric heaters have nickel-chrome
elements and utilize single point power connection.
INSPECTION
Assoonas aunitisreceived, itshouldbe inspectedforpossible
damage during transit. If damage is evident, the extent of the
damage should be noted on the carrier's freight bill. Aseparate
request for inspection by the carrier's agent should be made in
writing. See local distributor for additional information.
REFERENCE
Additional information on the design, installation, operation
and service of this equipment is available in the following
reference forms:
•
55.70-N1 -General Installation
•
55.70-N2 -Pre-start & Post-start Check List
•
530.18-N1.2V -Economizer Accessory
•
530.18-N1.4V -Fixed Outdoor Air Damper Accessory
•
530.18-N1.6V -Motorized Outdoor Air Damper Accy.
•
530.18-N7.1V -Electric Heater Accessory
• 530.18-N7.2V -Fuse Block Accessory
Renewal Parts:
•
Refer to Parts Manual for complete listing of replacement
parts on this equipment.
All forms referenced in this instruction may be ordered from:
Standard Register
Toll Free Tel: (405) 691-1126
Toll Free Fax: (405) 799-7746
APPROVALS
These units are designed and manufactured as follows:
1. For use as a heat pump only unit or a heat pump unit with
supplemental electric heat.
2. For outdoor installation only.
®
SUNLINE 2000
SINGLE PACKAGE HEAT PUMPS
INSTALLATION INSTRUCTION
Supersedes: 511.13-N1YI (900)/035-12984-000
035-12984-001-A-0204
Installershould pay particularattention to the words: NOTE, CAUTION and WARNING.Notes
are intendedto clarify or make the
installation easier. Cautions
are given to prevent equipment damage. Warnings are given to alert installer that personal injury
and/or equipment damage may result if installation procedure is not handled properly.
MODELS B3CH 048 AND 060
(WORLD 50 HZ)
CAUTION
THE ENCLOSED INSTALLATION INSTRUCTIONS AND ANY APPLICABLE
LOCAL, STATE, AND NATIONAL CODES INCLUDING, BUT NOT LIMITED
TO, BUILDING, ELECTRICAL, AND MECHANICAL CODES.
THIS PRODUCT MUST BE INSTALLED IN STRICT COMPLIANCE WITH
WARNING
OPERATION OF THE PRODUCT COULD CAUSE PERSONAL INJURY
OR PROPERTY DAMAGE.
INCORRECT INSTALLATION MAY CREATE A CONDITION WHERE THE
