16
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Outside Combustion Air Kits
(with duct) 81L87 FOAK-4
(without duct) 81L88 FOAK-4LD
INSTALLATION ACCESSORIES
The following accessory items are available
for use in the installation of this appliance.
Outside Air Kits Models FOAK and FOAK-LD
Outside Air kits are available with duct (FOAK-
4) and without duct (FOAK-4LD) for use if
outside combustion air is required or desired.
If model FOAK-4LD is used it must be used in
conjunction with locally purchased, non-com-
bustible Class 1 or Class 0 flexible duct.
COLD CLIMATE INSULATION
If you live in a cold climate, seal all cracks
around your appliance with noncombustible
material and wherever cold air could enter the
room. It is especially important to insulate
outside chase cavity between studs and under
floor on which appliance rests, if floor is above
ground level.Ensure that the clearance require-
ments for venting are always maintained.
To avoid air intrusion, surround material must
be caulked where it meets the black metal
facing of the appliance. Only use a noncom-
bustible caulking material to seal this area.
Do not place insulation materials within the 1"
gas vent system clearance space.
GAS CONVERSION KITS
In Canada
THE CONVERSION SHALL BE CARRIED OUT
IN ACCORDANCE WITH THE REQUIREMENTS
OF THE PROVINCIAL AUTHORITIES HAVING
JURISDICTION AND IN ACCORDANCE WITH
THE REQUIREMENTS OF THE CAN1-B149.1
AND .2 INSTALLATION CODE.
LA CONVERSION DEVRA ÊTRE EFFECTUÉE
CONFORMÉMENT AUX RECOMMANDATIONS
DES AUTORITÉS PROVINCIALES AYANT
JURIDICTION ET CONFORMÉMENT AUX
EXIGENCES DU CODE D'INSTALLATION CAN1-
B149.1 ET.2.
Note: These kits contain a main orifice which
can be used for installation at elevations of
0-2000 Ft. (610 m.) For elevations greater
than that, use the correct orifice as shown in
table 2 on page 2.
Kit part numbers are listed on the next page
and the following steps detail the conversion
procedure.
WARNING: THIS CONVERSION KIT SHALL BE INSTALLED
BY A QUALIFIED SERVICE AGENCY IN ACCORDANCE WITH
THE MANUFACTURER'S INSTRUCTIONS AND ALL APPLI-
CABLE CODES AND REQUIREMENTS OF THE AUTHORIZED
AGENCY HAVING JURISDICTION. IF THE INFORMATION IN
THESE INSTRUCTIONS ARE NOT FOLLOWED EXACTLY, A
FIRE, EXPLOSION OR PRODUCTION OF CARBON MONOX-
IDE MAY RESULT CAUSING PROPERTY DAMAGE, PER-
SONAL INJURY OR LOSS OF LIFE. THE INSTALLATION IS
NOT PROPER AND COMPLETE UNTIL THE OPERATION OF
THE CONVERTED APPLIANCE IS CHECKED AS SPECIFIED IN
THE OWNER INSTRUCTIONS SUPPLIED WITH THE KIT.
AVERTISSEMENT: CET ÉQUIPEMENT DE CONVERSION
SERA INSTALLÉ PAR UNE AGENCE QUALIFIÉE DE SER-
VICE CONFORMÉMENT AUX INSTRUCTIONS DU
FABRICANT ET TOUTES EXIGENCES ET CODES
APPLICABLES DE L'AUTORISÉS AVOIR LA JURIDICTION.
SI L'INFORMATION DANS CETTE INSTRUCTION N'EST
PAS SUIVIE EXACTEMENT, UN FEU, EXPLOSION OU PRO-
DUCTION DE PROTOXYDE DE CARBONE PEUT RÉSULTER
LE DOMMAGES CAUSER DE PROPRIÉTÉ, PERTE OU
BLESSURE PERSONNELLE DE VIE. L'AGENCE QUALIFIÉE
DE SERVICE EST ESPONSABLE DE L'INSTALLATION
PROPRE DE CET ÉQUIPMENT. L'INSTALLATION N'EST
PAS PROPRE ET COMPLÉTE JUSQU'À L'OPÉRATION DE
L'APPAREIL CONVERTI EST CHÉQUE SUIVANT LES
CRITÈRES ÉTABLIS DANS LES INSTRUCTIONS DE
PROPRIÉTAIRE PROVISIONNÉES AVEC L'ÉQUIPEMENT.
Step 1. Turn off the gas supply to the appliance.
Open the doors or remove the enclosure panel.
Step 2. Carefully remove the two (5500 Mod-
els) or four (6500 Models) smaller logs on top.
Then remove the two (2) main logs. Exercise
care as not to break the logs.
Gas conversion kits are available to adapt your
appliance from the use of one type of gas to the
use of another. These kits contain all the neces-
sary components needed to complete the task
including labeling that must be affixed to en-
sure safe operation.
