4830 & 4832
Inserting a bobbin
• Raise presser foot.
• Turn hand wheel toward you until needle is
in its highest position.
• Open slide plate and remove empty bob-
bin.
1. Pull 4" (10 cm) of thread from replacement
bobbin and insert bobbin into case as
shown.
2. Holding bobbin in place guide thread into
notch (1) and then down the slot to the left
and guide around into notch (2).
3. Draw several inches of thread diagonally
across the bobbin toward the back of the
machine.
4. While holding thread on outside, close the
slide plate allowing thread to extend
through the slot between the slide plate
and needle plate.
