17
Roof Sheathing
Rain Cap
Roof Flashing
Roof Rafters
Ceiling Joists
Vent Pipe
Exterior Wall
Sheathing
Outside Vent
Termination
Installation
TYPICAL THROUGH WALL WITH EXTERIOR BLOWER KIT INSTALLATION - VERTICAL TERMINATION:
Follow the previous pages for through wall installations. Ensure that vent pipe is properly secured to wall
using wall straps. Maintain clearances to combustibles on vent pipe as well as unit.
Figure 23: Through Wall Installation with Exterior Blower Kit; Vertical Termination.
