12427-2-0903
Page 15
INDEX PART
NO. NUMBER DESCRIPTION
INDEX PART
NO. NUMBER DESCRIPTION
PLEASE NOTE: When ordering parts, it is very important that part number and description of part coincide.
1 WFA-115 GASKET - HEADER
2 DV-1247 TOP PLATE (USA)
2 15668 TOP PLATE (CANADA)
3 R-3165 DOOR CLIP (2 REQUIRED)
4 DV-1204 CASING SIDE - RIGHT
5 DV-1203 CASING BACK
6 DV-1205 CASING SIDE - LEFT
7 DV-1248 AIR DROP (INCLUDES NO. 54)
8 DV-1231 TURBULATOR (3 REQUIRED)
9 DV-1250 DIVIDER PLATE
10 DV-1234 OUTLET BOX
11 DV-1225 OUTLET BOX COVER
12 R-3177 VENT SAFETY SWITCH
13 R-3161 FAN BLADE
14 R-3166 FAN MOTOR
15 DV-1246 MOTOR MOUNTING BRACKET
16 8720130 BUSHING (5 REQUIRED)
17 8520141 RUBBER GROMMET
(4 REQUIRED)
18 8520142 BRASS BUSHING
(4 REQUIRED)
19 R-3164 DOOR CLIP (2 REQUIRED)
20 DV-1251 INNER SHIELD - RIGHT
(INCLUDES NO. 23)
21 R-6176 FAN CONTROL SWITCH
22 R-3176 LIMIT SWITCH
23 DV-1253 INNER SHIELD COVER PLATE
(2 REQUIRED)
24 DV-1254 INNER SHIELD FRONT (USA)
24 15669 INNER SHIELD FRONT
(CANADA)
25 R-3163 FILTER RETAINER
26 R-3162 FILTER
27 DV-1252 INNER SHIELD -LEFT
(INCLUDES NO. 23)
28 DV-1256 EXCHANGER ASSEMBLY
29 DV-1235 PILOT BRACKET (IP ONLY)
30 R-3232 PILOT - NAT (IP ONLY)
30 R-3233 PILOT - LPG (IP ONLY)
31 742121 ORIFICE - NAT (3 REQUIRED)
31 P-88-60 ORIFICE - LPG (3 REQUIRED)
32 DV-1236 MANIFOLD
33 DV-1258 FRONT PANEL
34 722040 MANIFOLD UNION
35 852051 BUSHING 3/8 x 1/2
36 R-5655 GAS VALVE - LPG (SPP ONLY)
36 R-2148 GAS VALVE - NAT (SPP ONLY)
36 R-3170 GAS VALVE - NAT (IP ONLY)
36 R-3171 GAS VALVE - LPG (IP ONLY)
37 R-2708 PIEZO IGNITOR (SPP ONLY)
38 FF-160 PIEZO BRACKET (SPP ONLY)
39 DV-1318 OBSERVATION HOLE COVER
PLATE
40 DV-1242 BURNER COMPARTMENT FRONT
(SPP ONLY)
41 DV-1237 BURNER COMPARTMENT BODY
42 712045 MANIFOLD GASKET
43 GWT-168 AIR SHUTTER FRONT
(LPG ONLY)
44 GWT-169 AIR SHUTTER REAR
(LPG ONLY)
45 R-3031 BURNER (3 REQUIRED)
46 DV-1239 BURNER BRACKET
47 UH-452 TRANSFORMER MOUNTING
BRACKET (IP ONLY)
47 UH-810 TRANSFORMER MOUNTING
BRACKET (SPP ONLY)
48 R-1995 TRANSFORMER (SPP ONLY)
48 8720100 TRANSFORMER (IP ONLY)
49 UH-451 JUNCTION BOX COVER
50 DV-572 JUNCTION BOX
51 DV-1260 COVER PLATE - AIR DROP
52 872056 BUSHING
53 872053 CORD SET
54 8720148 BUSHING
55 DV-1215 BOTTOM PLATE
56 R-3034 PILOT - NAT (SPP ONLY)
56 R-3035 PILOT - LPG (SPP ONLY)
57 GWT-021 PILOT BRACKET (SPP ONLY)
58 R-3180 ELECTRODE AND WIRE
(SPP ONLY)
59 R-2256 THERMOCOUPLE -18"
(SPP ONLY)
60 R-6389 WALL THERMOSTAT - 24 VOLT
NOT SHOWN DV-1261 PILOT TUBING
NOT SHOWN 742158 PILOT ORIFICE - NAT (SPP ONLY)
NOT SHOWN 742266 PILOT ORIFICE - LPG (SPP ONLY)
NOT SHOWN 742154 PILOT ORIFICE - NAT (IP ONLY)
NOT SHOWN R-3265 PILOT ORIFICE - LPG (IP ONLY)
NOT SHOWN R-3172 WIRE HARNESS (SPP ONLY)
NOT SHOWN R-3173 WIRE HARNESS (IP ONLY)
NOT SHOWN R-1587C VENT SAFETY WIRE ASSEMBLY
How To Order Repair Parts...
Parts can be ordered only through your service person or dealer. For best results, the service person or dealer should order parts through the distributor.
Parts can be shipped directly to the service person/dealer.
All parts listed in the Parts List have a Part Number. When ordering parts, first obtain the Model Number from the name plate on your equipment. Then
determine the Part Number (not the Index Number) and the Description of each part from the following appropriate illustration and list. Be sure to give
all this information . . .
Furnace Model Number Part Description
Furnace Serial Number Part Number
Type of Gas (Propane or Natural)
Do not order bolts, screws, washers or nuts. They are standard hardware items and can be purchased at any local hardware store.
Shipments contingent upon strikes, fires and all causes beyond our control.
Empire Comfort Systems, Inc. Nine Eighteen Freeburg Ave. Belleville, Illinois 62222-0529
USE ONLY MANUFACTURER'S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INJURY OR DEATH.
