EURO 25 -1 10
MINIMUM MASONRY FIREPLACE DIMENSIONS
17” (432 mm)
25” (635 mm)
12” (305 mm)
TOP VIEW
The standard flue adapter will fit if X is more than 5 ¾”. It will also fit if X is less than 5 ¾” but Y is
higher than 8” (See ‘Flue connector, offset vent’ diagram)
19 ½” (495 mm)
SIDE VIEW
X
Y
Z
Flue connector
straight-up vent
Flue connector
offset vent
Flue connector
straight-up vent
Flue connector
offset vent
INSTALLATION INSTRUCTIONS - Continued
