EURO 25 -1 11
INSTALLATION INSTRUCTIONS - Continued
Flue connector
straight-up vent
Flue connector
offset vent
Flue connector
straight-up vent
Flue connector
offset vent
MINIMUM ZERO-CLEARANCE WOOD BURNING FIREPLACE DIMENSIONS
17” (432 mm)
25” (635 mm)
12” (305 mm)
TOP VIEW
15 ¼” (387 mm)
X
Y
Z
SIDE VIEW
The standard flue adapter will fit if X is more than 5 ¾”. It will also fit if X is less than 5 ¾” but Y is
higher than 8” (See ‘Flue connector, offset vent’ diagram)
