PROCEDURES:
1. Unit factory charge listed on the unit nameplate includes refrigerant for the condenser, the smallest evaporator and 15 feet of interconnect-
ing line tubing.
2. Verify the TXV or orifice and additional charge required for specific evaporator coil in the system using the above table.
3. Additional charge for the amount of interconnecting line tubing greater than 15 feet at the rate specified in Physical and Electrical Data
Table.
4. For TXV match charge weight needs to be weighed in for specififc coil match and lineset length.
5. Permanently mark the unit nameplate with the total system charge. Total System Charge = Base Charge (as shipped) + adder for evapo-
rator + adder for line set.
Additional R-410A Charge / Orifice Size for Various Matched Systems
Outdoor Unit
THGD18
S41S1
THGD24
S41S1
THGD30
S41S1
THGD36
S41S1
THGD42
S41S1
THGD48
S41S1
THGD60
S41S1
Required Orifice or TXV
1,2
1TVM0901 1TVM0903 1TVM0903 1TVM0904 1TVM0904 1TVM0905 1TVM0906
Factory Charge, lbs-oz 6 - 5 8 - 7 9 - 12 9 - 15 9 - 12 13 - 9 13 - 6
Indoor Coil
3,4
Additional Charge, Oz
FC/MC/PC/UC18AB 0 ––––––
FC/MC/PC/UC24AB + 4 0 –––––
FC/MC/PC30AB –0 –––––
FC/MC/PC32A –0 0 ––––
FC/MC/PC35BC –0 0 ––––
FC/MC/PC37A ––0 0 –––
FC/MC/PC43BC ––0 0 –––
FC/MC/PC/UC48CD – – – + 10 0 0 –
FC/MC/PC/UC60CD ––––0 0 –
FC/MC62D –––––+ 12 0
HC18A + 1 ––––––
HC30A + 10 0 –––––
HC36B –0 0 ––––
HC42 – – 0 0 0 – –
HC60 ––––0 0 –
HD24 + 14 ––––––
HD36 –+ 2 –––––
HD48 – – + 8 + 8 – – –
HD60 ––––0 + 7 –
AHP18 0 ––––––
AHP30 –0 –––––
AHP36 ––0 0 –––
AHP/SHP48 ––––0 0 –
AHP/SHP60 –––––0 –
AV24 + 3 0 –––––
AV36 – 6 0 0 – – –
AV/SV48 ––––0 0 –
AV/SV60 –––––0 –
F4FP24
0 ––––––
F4FP30
–0 –––––
F4FP40
––0 ––––
F4FP45
–––0 0 ––
F5FP48
––––0 0 –
F4FV60
–––––0 –
F5FP60
–––––0 –
FOOTNOTES:
1. For applications requiring a TXV use 1TVM900 series kit.
2. Approved orifice shipped with outdoor unit.
3. Systems matched with furnace or air handlers not equipped with blower-off delays may require blower Time Delay Kit 2FD06700224.
4. PC coils cannot be used in downflow or horizontal applications. FC coils cannot be used in horizontal applications.
See Caution below
See Caution below
See Caution below
See Caution below
See Caution below
See Caution below
See Caution below
F*FP Air Handlers come with a factory installed R-22 TXV which MUST BE CHANGED OUT to R-410A TXV or an orifice for proper opera-
tion. If the TXV is not changed out system damage will occur.
