397763-YTG-B-0508
28 Johnson Controls Unitary Products
Multipliers for determining the performance with other indoor sections.
HEATING PERFORMANCE DATA
CONDENSING UNIT MODEL NO THGD42S41S1
EVAPORATOR COIL MODEL NO FC/MC/PC/UC48
AIR TEMP.
ENTERING
OUTDOOR UNIT
AIR TEMP.
ENTERING
INDOOR COIL
ID CFM
1200 1400 1600
MBTUH KW C.O.P. MBTUH KW C.O.P. MBTUH KW C.O.P.
60
60 48.7 3.5 4.1 48.7 3.5 4.1 48.7 3.4 4.2
70 47.8 3.8 3.6 48.6 3.8 3.7 49.5 3.8 3.8
80 46.8 4.2 3.3 48.6 4.2 3.4 50.3 4.1 3.6
47
60 42.5 3.3 3.8 42.9 3.3 3.8 43.3 3.2 3.9
70 42.3 3.6 3.4 42.7 3.6 3.5 43.1 3.6 3.6
80 42.0 3.9 3.1 42.4 3.9 3.2 42.9 3.9 3.3
40
60 40.1 3.2 3.7 40.5 3.2 3.7 40.8 3.2 3.8
70 39.1 3.5 3.3 39.6 3.5 3.3 40.0 3.5 3.4
80 38.2 3.8 2.9 38.7 3.8 3.0 39.2 3.8 3.0
30
60 33.5 3.8 2.6 33.8 3.7 2.7 34.1 3.7 2.7
70 34.8 3.4 3.0 34.5 3.4 3.0 34.1 3.4 2.9
80 36.2 3.1 3.4 35.1 3.1 3.3 34.1 3.1 3.2
17
60 27.8 3.6 2.2 28.4 3.6 2.3 29.1 3.6 2.4
70 28.3 3.3 2.5 28.8 3.3 2.5 29.2 3.3 2.6
80 28.8 3.0 2.8 29.1 3.0 2.8 29.4 3.0 2.8
10
60 26.3 3.6 2.1 26.9 3.6 2.2 27.6 3.6 2.2
70 25.6 3.3 2.3 26.8 3.3 2.4 28.0 3.3 2.5
80 24.8 3.0 2.4 26.6 3.0 2.6 28.4 3.0 2.8
NOTE: ALL CAPACITIES ARE NET (KBTUH) WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil MBH KW COP
– FC/MC/PC60 1.00 1.06 0.94
– HC42 0.99 0.99 1.00
– HC60 1.00 1.06 0.94
– HD60 0.99 0.89 1.11
AHP/SHP48 – 1.00 1.00 1.00
AV48 – 0.99 1.05 0.94
F4FP045 – 1.01 1.07 0.94
F5FP048 – 0.99 1.01 0.98
MA14D FC/MC/PC48D 1.00 1.00 1.00
MA16C FC/MC/PC48C 1.00 1.00 1.00
MV16C FC/MC/PC48C 0.99 0.99 1.00
MV20D FC/MC/PC48D 0.98 0.98 1.00
MA14D FC/MC/PC60D 1.00 1.06 0.94
MA16C FC/MC/PC60C 1.00 1.06 0.94
MV20D FC/MC/PC60D 0.98 1.04 0.94
Variable Speed
Furnace
Coil MBH KW COP
PV8*C16 FC/MC/PC48C 0.99 0.99 1.00
PV8*C20 FC/MC/PC48C 0.99 0.99 1.00
P(C,V)9*C16 FC/MC/PC48C 0.99 0.99 1.00
P(C,V)9*C20 FC/MC/PC48C 0.99 0.99 1.00
P(C,V)9*D20 FC/MC/PC48D 0.99 0.99 1.00
PV8*C16 FC/MC/PC60C 0.99 1.05 0.94
PV8*C20 FC/MC/PC60C 0.99 1.05 0.94
P(C,V)9*C16 FC/MC/PC60C 0.99 1.05 0.94
P(C,V)9*C20 FC/MC/PC60C 0.99 1.05 0.94
P(C,V)9*D20 FC/MC/PC60D 0.99 1.05 0.94
PV8*C16 HC42C 0.99 0.98 1.00
PV8*C20 HC42C 0.98 0.98 1.00
P(C,V)9*C16 HC42C 0.99 0.99 1.00
P(C,V)9*C20 HC42C 0.98 0.98 1.00
P(C,V)9*D20 HC60D 0.99 1.05 0.94
PV8*C16 HD60C 0.98 0.88 1.11
PV8*C20 HD60C 0.98 0.88 1.11
P(C,V)9*C16 HD60C 0.98 0.88 1.11
P(C,V)9*C20 HD60C 0.98 0.88 1.11
P(C,V)9*D20 HD60D 0.98 0.88 1.11
