Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
CONDENSING UNIT MODEL NO. THGD60S41S1
INDOOR COIL MODEL NO. FC/MC62
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 1400 1600 1800
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65
T.C. 54.0 57.1 56.9 62.3 67.6 56.0 57.9 57.8 63.4 69.1 58.0 58.7 58.7 64.4 70.5
S.C. 56.0 51.0 43.4 42.9 34.8 58.1 54.4 45.4 45.0 36.2 60.1 57.7 47.4 47.1 37.6
KW 2.8 2.8 2.8 2.9 2.9 2.8 2.8 2.8 2.9 2.9 2.8 2.8 2.8 2.9 2.9
75
T.C. 51.9 54.1 53.9 59.2 64.5 53.7 54.9 54.8 60.2 65.7 55.5 55.7 55.6 61.2 66.9
S.C. 53.8 49.8 42.0 41.7 33.5 55.7 52.7 44.1 43.8 34.8 57.5 55.6 46.1 45.8 36.2
KW 3.2 3.2 3.2 3.3 3.3 3.2 3.2 3.2 3.3 3.3 3.2 3.2 3.2 3.3 3.3
85
T.C. 49.7 51.1 51.0 56.2 61.4 51.3 51.9 51.8 57.1 62.4 53.0 52.7 52.6 58.0 63.4
S.C. 51.6 48.6 40.7 40.5 32.2 53.2 51.1 42.8 42.5 33.4 54.9 53.6 44.9 44.6 34.7
KW 3.6 3.6 3.6 3.6 3.7 3.6 3.6 3.6 3.7 3.7 3.6 3.6 3.6 3.7 3.7
95
T.C. 47.6 48.1 48.1 53.1 58.3 49.0 48.9 48.8 54.0 59.0 50.4 49.7 49.5 54.8 59.8
S.C. 49.4 47.4 39.3 39.2 30.9 50.8 49.5 41.5 41.3 32.0 52.3 51.5 43.6 43.3 33.2
KW 4.0 4.0 4.0 4.0 4.1 4.0 4.0 4.0 4.1 4.1 4.0 4.0 4.0 4.1 4.1
105
T.C. 44.3 44.6 44.1 48.7 53.5 45.6 45.5 44.6 49.3 54.1 46.8 46.3 45.2 50.0 54.7
S.C. 45.9 44.7 37.6 37.4 29.0 47.2 46.3 39.7 39.4 30.2 48.5 48.0 41.8 41.5 31.3
KW 4.5 4.5 4.5 4.5 4.6 4.5 4.5 4.5 4.5 4.6 4.5 4.5 4.5 4.5 4.6
115
T.C. 41.1 41.3 40.2 44.4 48.9 42.2 42.2 40.6 44.9 49.4 43.3 43.1 41.0 45.3 49.9
S.C. 42.6 42.0 35.9 35.7 27.3 43.8 43.3 37.9 37.7 28.4 44.9 44.6 40.0 39.7 29.5
KW 4.9 5.0 4.9 5.0 5.0 5.0 5.0 4.9 5.0 5.0 5.0 5.0 5.0 5.0 5.0
125
T.C. 37.9 37.9 36.2 40.1 44.3 38.8 38.8 36.5 40.4 44.6 39.8 39.8 36.8 40.7 45.0
S.C. 39.3 39.3 34.2 33.9 25.5 40.3 40.3 36.2 35.9 26.6 41.2 41.3 38.2 37.9 27.7
KW 5.4 5.4 5.4 5.4 5.5 5.4 5.4 5.4 5.4 5.5 5.4 5.4 5.4 5.4 5.5
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
MA20D MC62D 1.00 1.00 1.00
MV20D MC62D 1.01 1.01 1.00
Variable Speed
Furnace
Coil T.C. S.C. KW
PV8*C20 MC62C 1.00 1.00 1.00
P(C,V)9*C20 MC62C 0.98 0.96 1.00
P(C,V)9*D20 MC62D 0.99 0.96 1.00
