26 Johnson Controls Unitary Products
Multipliers for determining the performance with other indoor sections.
HEATING PERFORMANCE DATA
CONDENSING UNIT MODEL NO THGD30S41S1
EVAPORATOR COIL MODEL NO AHP36
AIR TEMP.
ENTERING
OUTDOOR UNIT
AIR TEMP.
ENTERING
INDOOR COIL
ID CFM
800 1000 1200
MBTUH KW C.O.P. MBTUH KW C.O.P. MBTUH KW C.O.P.
60
60 33.0 2.5 3.9 35.7 2.4 4.3 38.5 2.4 4.7
70 31.4 2.6 3.6 34.1 2.6 3.9 36.9 2.6 4.2
80 29.8 2.7 3.2 32.5 2.7 3.5 35.2 2.7 3.8
47
60 28.8 2.3 3.6 30.6 2.3 3.9 32.3 2.3 4.1
70 26.6 2.4 3.2 28.3 2.4 3.4 29.9 2.4 3.6
80 24.4 2.5 2.9 26.0 2.5 3.0 27.6 2.5 3.2
40
60 25.8 2.2 3.4 27.1 2.3 3.5 28.4 2.3 3.7
70 24.2 2.3 3.0 25.4 2.3 3.2 26.6 2.4 3.3
80 22.6 2.4 2.7 23.7 2.4 2.8 24.7 2.5 2.9
30
60 19.3 2.3 2.5 19.9 2.3 2.5 20.4 2.4 2.5
70 20.8 2.2 2.7 21.5 2.3 2.8 22.2 2.3 2.9
80 22.3 2.2 3.0 23.1 2.2 3.1 24.0 2.2 3.2
17
60 13.3 2.1 1.9 14.8 2.1 2.0 16.3 2.2 2.2
70 15.4 2.1 2.2 16.5 2.1 2.3 17.7 2.1 2.4
80 17.4 2.0 2.5 18.2 2.1 2.6 19.0 2.1 2.7
10
60 13.0 2.0 1.9 10.0 2.1 1.4 6.9 2.1 1.0
70 14.5 2.0 2.1 13.4 2.0 1.9 12.2 2.1 1.7
80 16.0 2.0 2.4 16.7 2.0 2.5 17.5 2.0 2.5
NOTE: ALL CAPACITIES ARE NET (KBTUH) WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil MBH KW COP
– FC/MC/PC32 0.99 0.98 1.01
– FC/MC/PC35 0.99 0.98 1.01
– FC/MC/PC37 1.00 1.00 1.00
– FC/MC/PC43 1.00 1.00 1.00
– HC36 0.99 0.98 1.01
– HC42 1.00 1.00 1.00
– HD48 1.34 1.40 0.96
AHP36 – 1.00 1.00 1.00
AV36 – 0.98 0.98 1.00
F4FP040 – 0.99 0.98 1.02
MA12B FC/MC/PC35B 0.99 0.98 1.01
MV12B FC/MC/PC35B 0.97 0.96 1.01
MV16C FC/MC/PC35C 0.97 0.96 1.01
MA12B FC/MC/PC43B 1.00 1.00 1.00
MV12B FC/MC/PC43B 0.98 0.98 1.00
MV16C FC/MC/PC43C 0.98 0.98 1.00
Variable Speed
Furnace
Coil MBH KW COP
PV8*A12 FC/MC/PC32A 0.98 0.96 1.01
PV9*A12 FC/MC/PC32A 0.98 0.97 1.01
PV8*B16 FC/MC/PC35B 0.98 0.97 1.01
PV8*C16 FC/MC/PC35C 0.97 0.96 1.01
PV8*C20 FC/MC/PC35C 0.99 0.99 1.00
P(C,V)9*B12 FC/MC/PC35B 0.98 0.96 1.01
P(C,V)9*C16 FC/MC/PC35C 0.98 0.96 1.01
P(C,V)9*C20 FC/MC/PC35C 0.98 0.96 1.01
PV8*A12 FC/MC/PC37A 0.99 0.99 1.00
PV9*A12 FC/MC/PC37A 0.99 0.99 1.00
PV8*B16 FC/MC/PC43B 0.99 1.00 0.99
PV8*C16 FC/MC/PC43C 0.98 0.98 1.00
PV8*C20 FC/MC/PC43C 1.00 1.01 0.99
P(C,V)9*B12 FC/MC/PC43B 0.98 0.99 1.00
P(C,V)9*C16 FC/MC/PC43C 0.98 0.99 1.00
P(C,V)9*C20 FC/MC/PC43C 0.98 0.99 1.00
PV8*B16 HC36B 0.98 0.97 1.01
P(C,V)9*B12 HC36B 0.98 0.96 1.01
PV8*C16 HC42C 0.98 0.98 1.00
PV8*C20 HC42C 1.00 1.01 0.99
P(C,V)9*C16 HC42C 0.98 0.99 1.00
P(C,V)9*C20 HC42C 0.98 0.99 1.00
PV8*C16 HD48C 1.32 1.38 0.96
PV8*C20 HD48C 1.35 1.39 0.97
P(C,V)9*C16 HD48C 1.32 1.38 0.96
P(C,V)9*C20 HD48C 1.32 1.38 0.96
P(C,V)9*D20 HD48D 1.33 1.38 0.96
