CP equals MBH output divided by (total KW input x 3.412).
HSPF (Heating Seasonal Performance Factor) is the total heating output during a normal annual usage period for heating divided by
the total electric power input during the same period.
— = Not Applicable.
13 SEER HP WITH AV / SV / F*FV - VARIABLE SPEED
THGD18S41S1 AV24 – 16.8 3.62 1.36 11.5 3.18 1.06 8.00
THGD24S41S1
AV24 – 22.4 3.72 1.76 12.4 2.50 1.45 8.00
AV36 – 22.8 3.72 1.80 12.4 2.50 1.45 8.00
THGD30S41S1 AV36 – 27.6 3.64 2.22 16.0 2.50 1.88 8.00
THGD36S41S1 AV36 – 35.0 3.58 2.87 20.8 2.46 2.48 8.00
THGD42S41S1 AV/SV48 – 41.0 3.84 3.13 27.2 2.66 3.00 8.00
THGD48S41S1
AV/SV48 – 50.5 3.62 4.09 30.0 2.42 3.63 8.00
AV/SV60 – 50.5 3.62 4.09 30.2 2.40 3.69 8.00
F4FV060 – 50.5 3.62 4.09 30.2 2.40 3.69 8.00
13 SEER HP WITH AHP / SHP / F*FP
THGD18S41S1
AHP18 – 17.0 3.38 1.47 8.2 2.16 1.11 7.70
F4FP24 – 17.0 3.34 1.49 12.5 3.04 1.21 7.70
THGD24S41S1
AHP30 – 23.2 3.40 2.00 12.6 2.24 1.65 7.70
F4FP030 – 23.2 3.40 2.00 12.6 2.24 1.65 7.70
THGD30S41S1
AHP36 – 28.2 3.40 2.43 16.6 2.32 2.10 7.70
F4FP040 – 28.0 3.32 2.47 16.4 2.28 2.11 7.70
THGD36S41S1
AHP36 – 35.0 3.40 3.02 21.0 2.40 2.56 8.00
F4FP045 – 35.0 3.40 3.02 21.6 2.42 2.62 8.00
THGD42S41S1
AHP/SHP48 – 41.0 3.32 3.62 28.2 2.36 3.50 8.00
F4FP045 – 41.0 3.68 3.27 27.8 2.56 3.18 8.00
F5FP048 – 41.0 3.68 3.27 27.6 2.58 3.14 8.00
THGD48S41S1
AHP/SHP60 – 50.5 3.58 4.13 30.2 2.40 3.69 8.00
F5FP048 – 50.5 3.46 4.28 30.6 2.32 3.87 8.00
F5FP060 – 50.5 3.60 4.11 30.2 2.40 3.69 8.00
1. Rated CFM same as for cooling.
2. Heating MBH based on ARI standards of 70° DB entering indoor air, 72% RH outdoor air with 25 feet of interconnecting piping and
no supplemental electric heat operation.
HEATING PERFORMANCE - With Air Handler (Continued)
UNIT
MODEL*
AIR
HANDLER
COIL
1
MODEL
ARI HEATING
2
47°F17°FHSPF
MBH COP KW MBH COP KW STD
