292447-YIM-A-0507
Unitary Products Group 23
120
(10)
208 17.9 120.0 28.0 1.5 8.2 5.5 10.0
None - - - 61.5 67.0 70 80
E18 13.5 2 37.5 69.6 76.5 70 80
E24 18.0 2 50.0 85.2 92.1 90 100
E36 25.5 2 70.8 111.2 118.1 125 125
E54 40.6 2 112.7 163.6 170.5 175 175
230 17.9 120.0 28.0 1.5 8.2 5.5 10.0
None - - - 61.5 67.0 70 80
E18 18.0 2 45.2 76.9 83.8 80 90
E24 24.0 2 60.2 94.9 101.8 100 110
E36 34.0 2 85.3 125.0 131.9 125 150
E54 54.0 2 135.6 152.7 159.5 175 175
460 9.6 70.0 15.0 0.8 4.1 2.2 5.0
None - - - 32.3 34.5 40 40
E18 18.0 2 22.6 38.4 41.2 40 45
E24 24.0 2 30.1 47.5 50.2 50 60
E36 34.0 2 42.7 62.5 65.2 70 70
E54 54.0 2 67.8 76.3 79.1 90 90
575 7.4 53.0 11.5 0.6 3.6 1.8 4.0
None - - - 25.5 27.3 30 30
E18 18.0 2 18.1 31.2 33.4 35 35
E24 24.0 2 24.1 38.4 40.6 40 45
E36 34.0 2 34.1 50.4 52.6 60 60
E54 54.0 2 54.2 61.5 63.7 70 70
150
(12.5)
208 23.1 160.0 36.0 1.5 10.9 5.5 10.0
None - - - 78.9 84.4 100 100
E18 13.5 2 37.5 78.9 84.4 100 100
E24 18.0 2 50.0 88.6 95.5 100 100
E36 25.5 2 70.8 114.6 121.5 125 125
E54 40.6 2 112.7 167.0 173.9 175 175
230 23.1 160.0 36.0 1.5 10.9 5.5 10.0
None - - - 78.9 84.4 100 100
E18 18.0 2 45.2 80.3 87.1 100 100
E24 24.0 2 60.2 98.3 105.2 100 110
E36 34.0 2 85.3 128.4 135.2 150 150
E54 54.0 2 135.6 156.0 162.9 175 175
460 12.2 87.0 19.0 0.8 5.3 2.2 5.0
None - - - 41.0 43.2 50 50
E18 18.0 2 22.6 41.0 43.2 50 50
E24 24.0 2 30.1 49.0 51.7 50 60
E36 34.0 2 42.7 64.0 66.7 70 70
E54 54.0 2 67.8 77.8 80.6 90 90
575 8.7 62.0 13.5 0.6 4.1 1.8 4.0
None - - - 30.1 31.9 35 40
E18 18.0 2 18.1 31.8 34.0 35 40
E24 24.0 2 24.1 39.0 41.2 40 45
E36 34.0 2 34.1 51.0 53.3 60 60
E54 54.0 2 54.2 62.1 64.3 70 70
1. Minimum Circuit Ampacity.
2. Dual Element, Time Delay Type.
3. HACR type per NEC.
ZR078-150 Standard Motor - With Powered Convenience Outlet (Continued)
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Exh
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA
1
(Amps)
MCA
1
w/Pwr
Exh
(Amps)
Max Fuse
2
/
Breaker
3
Size
(Amps)
Max Fuse
2
/
Breaker
3
Size w/ Pwr
Exh
(Amps)
RLA LRA MCC FLA FLA FLA FLA Model kW Stages Amps
