Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. H2RC030S06
INDOOR COIL MODEL NO. G1FA036S17,21
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 800 1000 1200
ID DB (°F) 85 80 75 85 80 75 85 80 75
ID WB (°F) 72 67 63 72 67 63 72 67 63
75
T.C. 31.9 30.6 28.9 27.4 30.9 29.4 23.0 31.2 29.9
S.C. 18.9 19.1 18.9 19.7 20.1 20.3 20.5 21.2 21.8
KW 1.97 1.95 1.94 1.98 1.96 1.95 1.98 1.97 1.95
85
T.C. 31.4 29.3 27.0 28.2 30.1 28.9 25.0 30.6 30.9
S.C. 19.2 18.9 18.1 20.1 20.7 20.2 21.1 22.0 22.4
KW 2.16 2.13 2.09 2.15 2.15 2.13 2.14 2.16 2.16
95
T.C. 30.9 28.1 25.0 29.0 29.2 28.4 27.1 30.1 31.9
S.C. 19.5 18.7 17.3 20.6 20.7 20.1 21.6 22.8 22.9
KW 2.35 2.30 2.24 2.32 2.34 2.31 2.29 2.34 2.37
105
T.C. 28.6 25.5 22.3 28.2 26.8 24.6 27.9 27.8 26.8
S.C. 18.7 17.7 16.2 20.4 20.1 18.7 22.2 22.1 21.2
KW 2.53 2.45 2.40 2.53 2.49 2.44 2.53 2.51 2.48
115
T.C. 26.3 23.0 19.7 27.5 24.2 20.7 28.6 25.5 21.8
S.C. 17.9 16.7 15.2 20.3 19.0 17.3 22.8 21.3 19.5
KW 2.70 2.61 2.55 2.74 2.64 2.57 2.77 2.68 2.59
125
T.C. 24.0 20.4 17.0 26.7 21.7 16.8 29.4 23.2 16.7
S.C. 17.1 15.6 14.1 20.2 17.9 16.0 23.3 20.5 17.8
KW 2.88 2.76 2.70 2.94 2.79 2.70 3.00 2.84 2.69
NOTE: ALL CAPACITIES ARE NET WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil
T.C. S.C. KW
F2RP/F2FP030 1.01 1.08 0.99
F2RP/F2FP036 1.03 1.10 1.01
F2RC/F2FC030 0.99 1.01 0.99
F2RC/F2FC036 1.03 1.05 1.01
N1AHB1206 G2FD030(S,H)17 1.00 1.00 1.00
N1AHB1206 G2FD036(S,H)17 1.02 1.03 1.00
N1VSB12 G2FD036(S,H)17 1.03 1.12 0.94
N1VSB12 G2FD046(S,H)17 1.07 1.15 0.95
G1FA030S14 0.97 0.98 0.99
G1FA036S14 1.01 1.02 1.00
G1FA048S17 1.04 1.05 1.00
G1FA048S21 1.04 0.99 1.01
G1HD036 1.03 1.03 1.00
G1NA036S17L 1.05 1.05 1.01
G1NA030S17K 1.01 1.01 1.00
G1NA030S21M 1.01 1.01 1.00
G1UA030S14 0.97 0.98 0.99
G1UA036S14 1.01 1.02 1.00
G1UA036S17,21 1.00 1.00 1.00
G1UA048S17 1.04 1.05 1.00
G1UA048S21 1.04 0.99 1.01
G2FD030(S,H)17 1.00 1.00 1.00
G2FD035(S,H)14 1.00 1.00 1.00
G2FD036(S,H)17 1.02 1.03 1.00
G2FD036(S,H)21 1.03 1.03 1.00
G2FD042(S,H)21 1.03 1.04 1.00
G2FD046(S,H)17 1.05 1.05 1.01
Variable Speed
Furnace
Coil
T.C. S.C. KW
P1DUA12V G1FA030S14 0.99 0.99 0.94
P1DUA12V G2FD035(S,H)14 1.01 1.02 0.94
P1DUB16V G1FA036S17 1.02 1.03 0.94
P1DUB16V G2FD030(S,H)17 1.02 1.03 0.94
P1XDB12V G2FD030(S,H)17 1.02 1.03 0.97
P1XUB12V G1FA036S17 1.01 1.02 0.95
P1XUB12V G2FD030(S,H)17 1.01 1.02 0.95
P1XUC16V G1FA036S21 1.02 1.03 0.94
P1XUC16V G2FD036(S,H)21 1.05 1.06 0.94
